Sealing Profiles
Sealing Cords DI-SCHN
PA01019111_inh_EN.pdf Diameter from 6 mm to 12 mm PA01019111_inh_EN.pdf

container
Suitable for Industry Specific Applications
Schmalz - The Company

container
Applications
• Sealing cord for production of special, self-made suction plates Vacuum Knowledge
• Adaptation of suction plates to the dimensions of special
workpieces
• Handling of chipboard and MDF panels with cut-outs Suction Cups
Vacuum

Special Grippers

Vacuum Grip- ping Systems
Sealing cords DI-SCHN
container
Design Our Highlights... Your Benefits...

• Wear-resistant sealing cords made of silicon-free foam rubber in • Profiled sealing cord in any >Self-construction of "vacuum
various diameters and cross-sections desired length grippers" in any desired Mounting
shape and size to match Elements
special workpieces
• Wide range of diameters >Suitable for a wide range of
workpiece sizes and shapes
Vacuum Generators

container
Designation Code Sealing Cords DI-SCHN
container Valve Technology
Abbreviated designation Dimensions Material and Product addition
in mm Shore hardness*
Example DI-SCHN 8 MOS EPDM-20 SL:
DI-SCHN 8 MOS EPDM-20 SL Switches and
DI-SCHN 6 to 12 MOS EPDM-20 SL slot Monitoring
*Average Shore hardness

Filters and
container
Ordering Data Sealing Cords DI-SCHN Connections
Sealing cord DI-SCHN is delivered in the desired length.
container
Accounting unit 1 m.
Services
container
Sealing Cords DI-SCHN
container
Type Part Number
DI-SCHN 6 MOS EPDM-20 10.07.04.00001
DI-SCHN 8 MOS EPDM-20 10.07.04.00002 Contact
DI-SCHN 8 MOS EPDM-20 SL 10.07.04.00005
DI-SCHN 10 MOS EPDM-20 10.07.04.00003
DI-SCHN 12 MOS EPDM-20 10.07.04.00004
Index of Products

container
www.schmalz.com/di-schn
