Composite Grippers
Flow Grippers SCG
PA01019111_inh_EN.pdf Suction capacity from 270 l/min to 650 l/min PA01019111_inh_EN.pdf

container
Schmalz - The Company Suitable for Industry Specific Applications

container
Applications
Vacuum Knowledge • Gripper solution for handling dry food products such as cookies,
cakes and waffles
• Handling of products that require a high suction flow rate due to
their surface or geometry
Vacuum Suction Cups • The contact element made from FDA-compliant material allows
for direct, repeated contact with food products

Special Grippers

Vacuum Grip- ping Systems Flow gripper SCG Design

container

• Main body made from anodized aluminum with integrated
Mounting Elements • Base model available for axial (1) or side mounting (2)
compressed air-operated vacuum generation

• Suction cup connection nipple made from POM (material:
FDA-compliant) (3)
Vacuum Generators • Suction cup (4) with 1.5 folds (suction area Ø 50 mm) made from
silicone (material: FDA-compliant); large shaft diameter for high
flow rates
Valve Technology • Customer-specific suction areas on request

System Design Flow gripper SCG
Switches and Monitoring container Our Highlights... Your Benefits...

• Contact element made from >Suitable for direct use in the
FDA-compliant silicone
food product industry
Filters and Connections • Very high suction flow rate >Secure gripping even of
material
porous, highly textured
workpieces

Services • Compact suction bellows with >High lateral stability even
1.5 folds
with rapid acceleration
• Suction area with soft and >Excellent sealing and
flexible sealing lip damping on textured surfaces
such as cookies with frosting
Contact Flow gripper SCG for handling bakery products • Dirt-resistant vacuum >Long service intervals

generator
• Suction cup can be >Easy to clean
Index of Products disassembled without tools

354 www.schmalz.com/scg
