Page 55 - Destaco - Round Tooling Systems

08/200
07/175
04/100
05/125
[1.00]
“D1”
25.4
02/50
[3.63]
19.1
25.4
92.3 [1.00] 03/75 “A” [.75] 06/150
[1.57]
40.0
Transition Swivel Arms
M10 FASTENER “B” “D2”
“C”
Round Tooling | Dimensions and Technical Specifications
SAxx Single-Bolt Ø40mm/1.50” to Ø40mm/1.50”

03/75 08/200
04/100 07/175
05/125 06/150
[1.00]
25.4 “D”

“A”

[1.00] 02/50
[4.12] 25.4
104.6 [1.00]
[2.06] 25.4
52.3

“B”
M10 FASTENER “D”
“C”

Model Number (Ø)“D” “A” “B” “C” Weight FINISH

CPI-SA10-150-150-02 1.50”(in) SILVER
[2.84] [2.01] [4.17] [0.59 lb]
72.0 51.1 105.9 0.27 kg
CPI-SA25-40-40-50 40mm BLUE
CPI-SA10-150-150-03 1.50”(in) SILVER
[3.67] [3.07] [5.19] [0.69 lb]
93.2 78.1 131.9 0.31 kg
CPI-SA25-40-40-75 40mm BLUE
CPI-SA10-150-150-04 1.50”(in) SILVER
[4.52] [4.05] [6.17] [0.79 lb]
114.7 102.9 156.7 0.36 kg
CPI-SA25-40-40-100 40mm BLUE
CPI-SA10-150-150-05 1.50”(in) SILVER
[5.42] [5.04] [7.16] [0.88 lb]
137.7 128.0 181.9 0.40 kg
CPI-SA25-40-40-125 40mm BLUE
CPI-SA10-150-150-06 1.50”(in) SILVER
[6.35] [6.03] [8.15] [0.97 lb]
161.4 153.2 207.0 0.44 kg
CPI-SA25-40-40-150 40mm BLUE

CPI-SA10-150-150-07 1.50”(in) SILVER
[7.29] [7.01] [9.13] [1.09 lb]
185.2 178.1 231.9 0.49 kg
CPI-SA25-40-40-175 40mm BLUE
CPI-SA10-150-150-08 1.50”(in) SILVER
[8.25] [8.00] [10.12] [0.54 lb]
209.5 203.2 257.0 1.18 kg
CPI-SA25-40-40-200 40mm BLUE

EE-RND-55 Dimensions and technical information are subject to change without notice
