M10 FASTENERS [.75] "B" Transition Swivel Arms
"C" Ø19.1 M10 FASTENERS "D2"
"C"
M10 FASTENERS Round Tooling | Dimensions and Technical Specifications
M10 FASTENERS
EDxx Double-Bolt Ø40mm/1.50” to Ø40mm/1.50”
[1.00]
"D" 25.4
"A"
[2.10]
53.3 [1.00]
25.4 [4.12]
[1.00] 104.6
25.4 [2.10]
53.3
"B"
M10 FASTENERS "D"
"C"
M10 FASTENERS
Model Number (Ø)“D” “A” “B” “C” Weight FINISH
[4.56] [4.10] [6.22]
CPI-ED10-150-150-04 1.50”(in) SILVER
115.9 104.1 158.0 [0.76 lb]
[4.52] [4.05] [6.17] 0.34 kg
CPI-ED25-40-40-100 40mm 114.7 102.9 156.7 BLUE
[6.42] [6.10] [8.22]
CPI-ED10-150-150-06 1.50”(in) SILVER
163.1 154.9 208.8 [0.90 lb]
[6.35] [6.03] [8.15] 0.41 kg
CPI-ED25-40-40-150 40mm BLUE
161.4 153.2 207.0
[8.34] [8.10] [10.22]
CPI-ED10-150-150-08 1.50”(in) SILVER
211.9 205.7 259.6 [1.03 lb]
[8.25] [8.00] [10.12] 0.47 kg
CPI-ED25-40-40-200 40mm BLUE
209.5 203.2 257.0
[10.30] [10.10] [12.22]
CPI-ED10-150-150-10 1.50”(in) SILVER
261.5 256.4 310.4 [1.17 lb]
[10.17] [9.97] [12.09] 0.53 kg
CPI-ED25-40-40-250 40mm BLUE
258.3 253.2 307.1
[12.27] [12.10] [14.22]
CPI-ED10-150-150-12 1.50”(in) SILVER
311.5 307.3 361.2 [1.31 lb]
[12.11] [11.94] [14.06] 0.59 kg
CPI-ED25-40-40-300 40mm BLUE
307.5 303.3 357.1
[14.24] [14.10] [16.22]
CPI-ED10-150-150-14 1.50”(in) SILVER
361.7 358.1 411.98 [1.45 lb]
CPI-ED25-40-40-350 40mm [14.03] [13.90] [16.02] 0.66 kg BLUE
356.7 353.1 406.9
[16.22] [16.10] [18.22]
CPI-ED10-150-150-16 1.50”(in) SILVER
412.1 408.9 462.7 [1.59 lb]
[16.00] [15.87] [18.00] 0.72 kg
CPI-ED25-40-40-400 40mm BLUE
406.3 403.1 457.0
Dimensions and technical information are subject to change without notice EE-RND-56
