Plastics - Blue Slice
Round Tooling | Dimensions and Technical Specifications
[3.15] [.24]
80 Ø6
[1.99]
50.5
[3.71]
94.2
[.43]
[.28] 11
Ø7
[1.18]
30 [.47]
Model Number Material Weight
11.9
CPI-SGM-TH-12 Steel 604g [1.33 lb]
[4.72]
120
Name: Blue Slice Nest Tooling
Material: Blue Nylon, 1” (25.4mm) thickness
Benefits: Lightweight, durable, machinable material
Process: Machined from 3D CAD
