Page 8 - Destaco - Round Tooling Systems

“D”
“L”
CPI-PAB-10-XX, SOLID ROUND ROD
“D”
“L”
“D”
“L”
Tubes and Rods
CPI-PAT-XXT-XX, LIGHT WALL TUBING
CPI-PAB-10-XX, SOLID ROUND ROD
Round Tooling | Dimensions and Technical Specifications
CPI-PAT-15-XX, HEAVY WALL TUBING
BT1 Slotted Aluminum Boom/Tubing
“D”
“L”
“L“ = Specify Length “D” “L”
in 6.00” or 150mm Increments
English Example:
CPI-BTI-150-7S-06 (6.00”) [25.4]
CPI-PAT-XXT-XX, LIGHT WALL TUBING
[25.4]
1.00
1.00
Metric Example: CPI-PAT-15-XX, HEAVY WALL TUBING
CPI-BTI-150-7S-150 (150mm) 1/3 “L” AIR LINE
ACCESS SLOT
CPI-BTI-250-9S-XX, SLOTTED BOOM FOR TOOL CHANGER AIR OPTION
Model (Ø) “D” Wall Thickness Weight Linear Deflection Torsional Twist
“D”
[0.25”] [1.2 lb/ft] 5.6mm [0.22”] “L” .3.1°
CPI-BT1-150-7S-”L” 1.50”(in)
6.35mm 1.8 kg/m @ 100lb/24.00” @ 300ft-lbs
[0.25”] [2.1 lb/ft] 12.7mm [0.50”] 2.3°
CPI-BT1-250-9S-”L” 2.50”(in)
6.35mm 3.1 kg/m @ 150lb/48.00” @ 600ft-lbs
[25.4]
“L”
[25.4]
“D” 1.00
1.00
[0.375”] [2.9 lb/ft] 10.2mm [0.40”] 1.8°
CPI-BT1-2538-9S-”L” 2.50”(in) AIR LINE
1/3 “L”
9.53mm 4.3 kg/m @ 150lb/48.00” @ 600ft-lbs
ACCESS SLOT
[0.20”] [1.6 lb/ft] 17.8mm [0.70”] 3.3°
CPI-BT1-60-9S-”L” (Metric) 60mm CPI-BTI-250-9S-XX, SLOTTED BOOM FOR TOOL CHANGER AIR OPTION
5mm 2.4 kg/m @ 150lb/48.00” @ 600ft-lbs
CPI-PAT-25-XX, BOOM
PAT Aluminum Tubing
“L“ = Specify Length
“D” “L”
in 6.00” or 150mm Increments “D” “L”
English Example:
CPI-PAT-15-06 (6.00”)
Metric Example: CPI-HYD-TUBE-XX, STEEL ROUND TUBE
CPI-PAT-40-150 (150mm)

CPI-PAT-25-XX, BOOM

Model (Ø) “D” Wall Thickness Weight Linear Deflection Torsional Twist
[0.25”] [0.7 lb/ft] 1.5mm [0.06”] 2.4°
CPI-PAT-1025-”L” 1.00”(in) “D” “L”
6.35mm 1.02 kg/m @ 50lb/12.00” @ 100ft-lbs
[0.25”] [0.9 lb/ft] 3.3mm [0.13”] 1.6°
CPI-PAT-12-”L” 1.25”(in)
6.35mm 1.37kg/m @ 75lb/18.00” @ 100ft-lbs
CPI-HYD-TUBE-XX, STEEL ROUND TUBE
[0.25”] [1.2 lb/ft] 5.6mm [0.22”] .3.1°
CPI-PAT-15-”L” 1.50”(in)
6.35mm 1.8 kg/m @ 100lb/24.00” @ 300ft-lbs
[0.20”] [1.2 lb/ft] 5.6mm [0.22”] 3.2°
CPI-PAT-40-”L” (Metric) 40mm
5mm 1.8 kg/m @ 100lb/24.00” @ 300ft-lbs
[0.25”] [2.1 lb/ft] 12.7mm [0.50”] 2.3°
CPI-PAT-25-”L” 2.50”(in)
6.35mm 3.1 kg/m @ 150lb/48.00” @ 600ft-lbs
[0.20”] [1.6 lb/ft] 17.8mm [0.70”] 3.3°
CPI-PAT-60-”L” (Metric) 60mm
5mm 2.4 kg/m @ 150lb/48.00” @ 600ft-lbs
[0.375”] [2.9 lb/ft] 10.2mm [0.40”] 1.8°
CPI-PAT-2538-”L” 2.50”(in)
9.53mm 4.3 kg/m @ 150lb/48.00” @ 600ft-lbs

Dimensions and technical information are subject to change without notice EE-RND-8
