Vacuum Suction Cups Special Grippers

Vacuum suction cups come in a wide range of shapes, sizes The range of special grippers includes many variants with differ-
and materials. They act as the connecting element between ing sizes, shapes and principles of operation. They are used for
the machine and workpiece, and are used to lift and transport workpieces that cannot be gripped using vacuum suction cups.
objects of all kinds.

Flat Suction Cups (Round/Oval) Floating Suction Cups
For flat to slightly curved Floating suction cups enable contact-free han-
and narrow workpieces dling of sensitive workpieces using an air cush-
ion between the gripper and the surface.

Bellows Suction Cups (Round/Oval) Magnetic Grippers
Good adaptive charac- A permanent magnet ensures that sheets with
teristics suitable for holes, bores and gaps are held securely.
uneven workpieces

Suction Cups for Industry Applications Needle Grippers
Sheet metal/auto- Wood Porous and unstable workpieces such as textiles
motive Good han- Excellent properties or composite materials are held securely using
dling specifically for under harsh operat- retractable needles.
oily surfaces ing conditions

Packaging Plastics
For handling tasks in Specifically for mark- Thin Glass/Wafer Grippers
the fastest of pack- free gripping and tem- Thin glass/wafer grippers allow rapid and gentle
aging processes perature resistance handling as well as precise positioning of solar
wafers and thin glass.
Solar Electronics
Careful handling For all handling steps
of photovoltaic ELECTRONICS within the electronics
components production process Composite Grippers
Composite grippers ensure secure handling of
Glass porous, non-rigid or permeable workpieces such
Mark-free handling as plastic film, paper and wooden veneer.
of smooth, thin
workpieces

www.schmalz.com/suction-cups www.schmalz.com/special-grippers
