Page 5 - Schmalz - Vacuum Components Product Overview

Vacuum Area Gripping Systems Mounting Elements

and Vacuum End Effectors

With its vacuum area gripping systems that are supplied ready for Mounting elements combine vacuum components into efficient
connection, Schmalz provides innovative, integrated solutions for vacuum systems. The modular design ensures that the components
a diverse range of applications in virtually all automated handling are combined for optimum effect.
processes.

Area Gripping Systems FXP/FMP Sections and Connections
Automatic palletizing, picking and sorting of a High strength aluminum sections and a wide
range of different goods – just one area gripping range of accessories ensure a tailored base
system is all you need. structure for vacuum systems.

Area Gripping Systems SBX Holders
The area gripping system SBX was developed Holders provide a high level of flexibility during
specifically for very rugged applications in the the assembly and adjustment of grippers and
timber and woodworking industry and covers a spring plungers, as well as providing a simple
wide range of applications in the modular system. connection method with sections and pipes.

Vacuum End Effectors VEE Spring Plungers
Modular system for designing vacuum end Spring-mounted holders on grippers compensate
effectors and grippers for dynamic packaging for differences in height and enable soft place-
processes. ment on sensitive workpieces.

Jointed Mountings
Multi-directional jointed mountings enable opti-
mum adjustment of the vacuum suction cup on
uneven workpiece surfaces.

www.schmalz.com/gripping-systems www.schmalz.com/mounting-elements
