In-Line Water Absorbing Diesel Fuel Filter BDFA

*Coalescing Elements Patent Pending
Applications 16-32 gpm ICF

60-120 L/min BDF

100 psi BDFA
7 bar BDFA
BDA

QCF

BDS
Application Introduction:
The Reason for Better Bulk Fuel Filtration: BDS2
The BDFA1 and BDFA2 provide exceptional single-pass diesel
filtration and continuous water removal. Both filters combine BDS3
Schroeder’s fully synthetic Excellement Z-Media in a particulate
®
®
pre-filter, the KL3, with our fast-acting water absorbing filter, IRF, BDS4
to fully protect vital diesel engine components from dirt and water.
The BDFA1 and BDFA2 are ideal for fuel dispensing operations.
The filters can be installed on the inlet or outlet of a diesel LVH-F
fueling dispenser.
The BDFA1 is also ideal for generator sets in a single-pass or LVH-C
kidney loop installation. Model no. of filter in photograph is:
BDFA1VVM
BDFC

Features and Benefits BDC
■ Designed with integrated particulate removal pre-filter for
maximum absorbent filter performance in the downstream housing HDP-BC
■ Two stage filtration for particulate and water removal
through absorption HDP-HT
■ Particulate filtration at 1 or 3 microns utilizing Excellement
®
synthetic Z-Media element EPM
®
■ Water removal element capable of removing free and
emulsified water
■ Easy mounting and service Model no. of filter in photograph is: EPTT
BDFA2VVM
EWU
Markets BCC

SCHROEDER INDUSTRIES | FUEL FILTRATION 31
