Catalog 0802-E (Revised 02-04-15) Vacuum Generators
Replacement Components & Cautions CEK Add-A-Fold Assemblies

Replacement components Cautions
!
Item Part number Description Do not use or expose the CEK with fluids or corrosive gases.
1 CVK-S Silencer Vacuum Venturi’s are designed to be used with non-lubricated,
2 thru 7 CVK-F Filter kit non-corrosive, compressed air.
5 CVK-E Filter element Do not operate CEK generators outside the temperature
range and pressures listed in the specifications section of this
8, 10 MC2-24-B-10-D Blow-off Pilot Valve catalog. Regulate the compressed air to 70PSI and filtrate with
9, 10 MC2-24-B-10-V Air-Economizing Valve a maximum 40 micron filter. Non-lubricated compressed air will
10 MC2-5L 500mm clip lead maintain the life and vacuum level of the generator.
B 11,13 VA01PLC241PE Vacuum on / off valve, NPN Check the insulation of all lead wires after installation to avoid
shorts. Properly secure all lead wires to avoid stress or
Vacuum on / off valve, PNP
12,13
PCL241B-NB-D24UM
13 PCL2-D24-CL5 500mm clip lead repeated movement that may fray lead wires.
Item Part number Replacement sensor Some electrical components are diode or zener diode
MPS-V23C-NC MPS-V23 (NPN) option protected. When installing solenoids and sensors, check
14 the polarity of the component before applying power. Apply
MPS-V23C-PC MPS-V23 (PNP) option
the appropriate voltage to the solenoids and sensors.
Inappropriate voltage, shorts, or surges may damage the
circuitry.
Selection
Generator
Filter
Cap 2 13 Vacuum On /
Valve Mounting
Filter O-ring 3 Screws (M3x18) 11 12 Vacuum Off
CV-CK
(M8x1.0) Valve
MCA, CV,
1 Silencer
Filter 4 Valve Mounting
CHF
Housing Screws (M3x18)
10 Blow-Off
Filter 5 10 8 Pilot
Element Valve
Air-Economizing
MC22
Sensor 14 Valve
9
Sensor
Mounting 6
MC72
Brkt. Screws Filter
(M3x5) Gasket
Sensor Screws
O-Ring
CEK
(P5)
Sensor
Mounting
Brkt. Pressure
Port Block
CVXCEK
Sensor
Mounting O-ring
Screws
(M2x6) PL1-CB10, Optional Booted Cable
MPS-23
Black Wire, Solenoid B, Vacuum Off
Vacuum Filter Red Wire, Common
Port 7
Base White Wire, Solenoid A, Vacuum On
Black
MVS-201
Red
Pilot Valve Cable White
.83
MC2-5L (500mm) Lead* 1000mm (21mm)
(Connects Power Source to Vacuum
& Blow-off Release Pilot Valves) PCL2-D24-CL5* Cable
Generator
Accessories
Positive “+” (Red Wire) Black Wire, Solenoid B, Vacuum On
Negative “-” (Black Wire) MC2-CB10 Valve Cable
* Included with Generator Red Wire, Common
Yellow Wire, Solenoid A, Vacuum Off (Connects Power Source to Vacuum
Glossary
*Included with Generator & Blow-off Release Pilot Valves)
Positive “+” (Red Wire)
Black Negative “-” (Black Wire)
Red
Yellow
500mm
500mm,1000mm
or 1500mm 1000mm
