3 WINSTA MIDI
Cable Assemblies 5 x 2.5 mm²
152
PVC H05VV-F 5G2.5
halogen-free H05Z1Z1-F 5G2.5
400 V/6 kV/3 I 20 A
N
Conductor ends, bonded: 9 mm
1 Approvals
Interconnecting cable, socket – plug Length Item No. Item No. Item No. Item No.

white
black
white
black
Coding A
PVC halogen-free
1 m 771-9995/007-101 771-9995/007-102 771-9995/017-101 771-9995/017-102
2 m 771-9995/007-201 771-9995/007-202 771-9995/017-201 771-9995/017-202
3 m 771-9995/007-301 771-9995/007-302 771-9995/017-301 771-9995/017-302
4 m 771-9995/007-401 771-9995/007-402 771-9995/017-401 771-9995/017-402
<______69______> <______69______>
5 m 771-9995/007-501 771-9995/007-502 771-9995/017-501 771-9995/017-502
<___47___> L2 L1 3 L2 L1 3 <___47___> 7 m 771-9995/007-701 771-9995/007-702 771-9995/017-701 771-9995/017-702
L3
771-9995/017-602
771-9995/007-602
6 m
771-9995/017-601
771-9995/007-601
L3
8 m
771-9995/017-802
771-9995/017-801
771-9995/007-802
771-9995/007-801
N
N
<_____________________________________ L _____________________________________>
Connecting cable, socket – free end Length Item No. Item No. Item No. Item No.
white
black
white

black
Coding A
L3 PVC halogen-free
L2
L1
PE 1 m 771-9995/107-101 771-9995/107-102 771-9995/117-101 771-9995/117-102
N 2 m 771-9995/107-201 771-9995/107-202 771-9995/117-201 771-9995/117-202
3 m 771-9995/107-301 771-9995/107-302 771-9995/117-301 771-9995/117-302
4 m 771-9995/107-401 771-9995/107-402 771-9995/117-401 771-9995/117-402
<______69______> <______ 55 ______> 5 m 771-9995/107-501 771-9995/107-502 771-9995/117-501 771-9995/117-502
<___47___> L2 L1 3 6 m 771-9995/107-601 771-9995/107-602 771-9995/117-601 771-9995/117-602
L3
771-9995/117-701
771-9995/117-702
771-9995/107-701
7 m
771-9995/107-702
771-9995/107-801
771-9995/117-801
771-9995/107-802
771-9995/117-802
8 m
N
> 9 8<
<_____________________________________ L _____________________________________>
Connecting cable, plug – free end Length Item No. Item No. Item No. Item No.
white
black
white
black

Coding A
N
PE PVC halogen-free
L1
L2 1 m 771-9995/207-101 771-9995/207-102 771-9995/217-101 771-9995/217-102
L3 2 m 771-9995/207-201 771-9995/207-202 771-9995/217-201 771-9995/217-202
3 m 771-9995/207-301 771-9995/207-302 771-9995/217-301 771-9995/217-302
4 m 771-9995/207-401 771-9995/207-402 771-9995/217-401 771-9995/217-402
<______69______>
<______ 55 ______> 5 m 771-9995/207-501 771-9995/207-502 771-9995/217-501 771-9995/217-502
<___47___> 3 L1 L2 7 m 771-9995/207-701 771-9995/207-702 771-9995/217-701 771-9995/217-702
N
771-9995/217-602
771-9995/217-601
771-9995/207-602
6 m
771-9995/207-601
771-9995/207-802
771-9995/207-801
771-9995/217-802
771-9995/217-801
8 m
L3
> 9 8 <
<_____________________________________ L _____________________________________>
Info Accessories
Locking lever,for “flying leads”,
manually operated
1 For “International Certification Organizations” and black 770-101 100 (4x25)
“Approvals — User Guide”, white 770-121 100 (4x25)
see pages 300 to 303. Locking lever, for “flying leads”,
Marine approvals (GL, LR, NV) relate exclusively to tool operated
cables approved for marine applications. black 770-111 100 (4x25)
white 770-131 100 (4x25)
For other cables, please contact factory. Lockout cap, for socket, separable, 12-pole
black Coding A (N 3 L1 L2 L3) black 770-201 100
white Coding A (N 3 L1 L2 L3) white 770-221 100
blue Coding I (N 3 L DA- DA+) Lockout cap, for plug, separable, 5-pole

For coding information, see pages 284 to 286. yellow 770-360 100
Fire load data available upon request.
Recommended items are shown in red and available for immediate delivery!
