Page 157 - Wago_ThePluggableConnectionSystem_Volume5_2015_US.pdf

3

155
PVC H05VV-F 5G2.5
halogen-free H05Z1Z1-F 5G2.5
400 V/6 kV/3 I 20 A
N
Conductor ends, bonded: 9 mm
1 Approvals
Interconnecting cable, socket – plug Length Item No. Item No. Item No. Item No.
black

white
white
black
Coding P
PVC halogen-free
1 m 771-9975/007-101 771-9975/007-102 771-9975/017-101 771-9975/017-102
2 m 771-9975/007-201 771-9975/007-202 771-9975/017-201 771-9975/017-202 3
3 m 771-9975/007-301 771-9975/007-302 771-9975/017-301 771-9975/017-302
4 m 771-9975/007-401 771-9975/007-402 771-9975/017-401 771-9975/017-402
<______69______> <______69______> 5 m 771-9975/007-501 771-9975/007-502 771-9975/017-501 771-9975/017-502
<___47___> L2 L1 3 L2 L1 3 <___47___> 6 m 771-9975/007-601 771-9975/007-602 771-9975/017-601 771-9975/017-602
L3
L3
771-9975/007-701
7 m
771-9975/007-702
771-9975/017-701
771-9975/017-702
771-9975/017-801
8 m
771-9975/007-802
771-9975/007-801
771-9975/017-802
N
N
<_____________________________________ L _____________________________________>
Connecting cable, socket – free end Length Item No. Item No. Item No. Item No.

white
white
black
black
Coding P
L3 PVC halogen-free
L2
L1
PE 1 m 771-9975/107-101 771-9975/107-102 771-9975/117-101 771-9975/117-102
N 2 m 771-9975/107-201 771-9975/107-202 771-9975/117-201 771-9975/117-202
3 m 771-9975/107-301 771-9975/107-302 771-9975/117-301 771-9975/117-302
4 m 771-9975/107-401 771-9975/107-402 771-9975/117-401 771-9975/117-402
<______69______> 5 m 771-9975/107-501 771-9975/107-502 771-9975/117-501 771-9975/117-502
<______ 55 ______> 6 m 771-9975/107-601 771-9975/107-602 771-9975/117-601 771-9975/117-602
<___47___> L2 L1 3 7 m 771-9975/107-701 771-9975/107-702 771-9975/117-701 771-9975/117-702
L3
771-9975/107-802
771-9975/107-801
771-9975/117-802
771-9975/117-801
8 m
> 9 8<
N
<_____________________________________ L _____________________________________>
Connecting cable, plug – free end Length Item No. Item No. Item No. Item No.
black
white
black
white

Coding P
N
PE PVC halogen-free
L1
L2 1 m 771-9975/207-101 771-9975/207-102 771-9975/217-101 771-9975/217-102
L3 2 m 771-9975/207-201 771-9975/207-202 771-9975/217-201 771-9975/217-202
3 m 771-9975/207-301 771-9975/207-302 771-9975/217-301 771-9975/217-302
4 m 771-9975/207-401 771-9975/207-402 771-9975/217-401 771-9975/217-402
<______69______>
<______ 55 ______> 5 m 771-9975/207-501 771-9975/207-502 771-9975/217-501 771-9975/217-502
<___47___> 3 L1 L2 7 m 771-9975/207-701 771-9975/207-702 771-9975/217-701 771-9975/217-702
771-9975/207-602
6 m
N
771-9975/217-602
771-9975/217-601
771-9975/207-601
771-9975/217-802
771-9975/217-801
771-9975/207-802
771-9975/207-801
8 m
> 9 8 <
L3
<_____________________________________ L _____________________________________>
Accessories
Locking lever,for “flying leads”,
manually operated
black 770-101 100 (4x25)
white 770-121 100 (4x25)
Locking lever, for “flying leads”,
tool operated
black 770-111 100 (4x25)
white 770-131 100 (4x25)
Lockout cap, for socket, separable, 12-pole
black 770-201 100
white 770-221 100
Lockout cap, for plug, separable, 5-pole
yellow 770-360 100
WINSTA — perfectly plugged!
®
