P. 213
WINSTA RD 7
®
Plug Adapters for Attema’s Hollow-Wall Boxes
211
2.5 mm² 2.5 mm²
250 V/4 kV/3 250 V/4 kV/3
I 20 A I 20 A
N
N
L 16 mm / 0.63 in. L 16 mm / 0.63 in.
1 Approvals 1 Approvals
<_________ 130 _________> <___________ 130 ___________>
<___________ 138 ___________>
Description Color Item No. Pack. Unit Color Item No. Pack. Unit
Plug adapter, Plug adapter, for power outlets, Plug adapter, for switches,
3-pole coding A coding S
black 774-213/9900-0000 10 brown 774-1373/9900-0000 10
These plug adapters are designed for Attema’s hollow-wall boxes. They permit complete preassembly of switches and power outlets,
allowing them to be plugged on site via WINSTA RD connectors. Therefore, wiring switches and outlets is relocated from the con- 7
®
struction site to the factory, simplifying on-site installation and minimizing installation time.
Info
1 For “International Certification Organizations” and
“Approvals — User Guide”,
see pages 300 to 303.
black Coding A (L 3 N)
brown Coding S (L 2 1)
For coding information, see pages 284 to 286.
Fire load data available upon request.
WINSTA — perfectly plugged!
®
