WINSTA IDC 9
®
Flat Cables 5 x 4 mm and 5 x 2.5 mm + 2 x 1.5 mm 2
2
2
897 Series 227
Flat cable 5 x 4 mm² Flat cable 5 x 2.5 mm² + 2 x 1.5 mm 2 Flat cable 5 x 2.5 mm² + 2 x 1.5 mm 2
3L + N + PE 3L + N + PE + 2 Bus 3L + N + PE + 2 Bus
halogen-free halogen-free PVC
0.6/1kV 0.6/1kV 0.6/1kV

1 Approvals 1 Approvals 1 Approvals

Color Item No. Color Item No. Color Item No.
Flat cable 5 x 4 mm , Flat cable 5 x 2.5 mm + 2 x 1.5 mm 2 Flat cable 5 x 2.5 mm + 2 x 1.5 mm ,
2
2
2
2
halogen-free halogen-free PVC
black 897-453 violet 897-262 violet 897-261

Item-Specific Accessories
Flat cable end cover, plastic. Every cable end must be fitted Flat cable end cover, plastic. Every cable end must be fitted Flat cable end cover, plastic. Every cable end must be fitted
with an end cover. with an end cover. with an end cover.
transparent 897-250 10 transparent 897-260 10 transparent 897-260 10
Insulating tape for flat cables, for sealing contact holes in Insulating tape for flat cables, for sealing contact holes in Insulating tape for flat cables, for sealing contact holes in
flat cables. flat cables. flat cables.
black 897-900 10 black 897-900 10 black 897-900 10
Fixing clamp, plastic, for screw mounting Fixing clamp, plastic, for screw mounting Fixing clamp, plastic, for screw mounting
9
gray 897-878 100 gray 897-878 100 gray 897-878 100
Stripping pliers Stripping pliers Stripping pliers
897-971 1 897-971 1 897-971 1
Cutter Cutter Cutter
897-972 1 897-972 1 897-972 1
Dimensions

( 6,1 ) ( 6,1 ) ( 6,1 )
<_______ 24,1 _______> <___________ 31,9 ___________> <___________ 31,9 ___________>
