Connectors and Headers
MCS MINI / MINI HD / MINI SL 4
4
239

3.5 and 3.81 mm pin spacing / Nominal cross section 1.5 mm 2

Pin Spacing Pages
MCS MINI
Female Connectors,
®
CAGE CLAMP Termination 3.5/3.81 mm / 0.138/0.15 in. 242 – 245
®
CAGE CLAMP S 3.5/3.81 mm / 0.138/0.15 in. 246 – 249
MCS MINI
Male Headers with Solder Pins 3.5/3.81 mm / 0.138/0.15 in. 250 – 257 4
Male Headers with Press-In Pins 3.5/3.81 mm / 0.138/0.15 in. 253 – 256
Male Headers for Through-Hole
Reflow Soldering 3.5/3.81 mm / 0.138/0.15 in. 258 – 261

MCS MINI
Male Connectors,
®
CAGE CLAMP Termination 3.5 mm/0.138 in. 262 – 264
3.81 mm/0.15 in. 264 – 265

MCS MINI
2-Conductor Combi Strips,
CAGE CLAMP Termination 3.5 mm/0.138 in. 266 – 267
®

MCS MINI
Female Connectors with Solder Pins 3.5 mm/0.138 in. 268 – 270
3.81 mm/0.15 in. 270 – 271

MCS MINI HD
Female Connectors,
CAGE CLAMP Termination 3.5 mm/0.138 in. 282 – 283
®

MCS MINI HD
Male Headers with Solder Pins 3.5 mm/0.138 in. 284 – 287
Male Headers with Solder Pins
for Through-Hole Reflow Soldering 3.5 mm/0.138 in. 288 – 394

MCS MINI SL
Female Connectors with Push-Buttons,
CAGE CLAMP S 3.5 mm/0.138 in. 300 – 301
®

MCS MINI SL
Male Headers with Solder Pins 3.5 mm/0.138 in. 302 – 303

MCS MINI Accessories 272 – 278
MCS MINI HD Accessories 296 – 297
MCS MINI SL Accessories 303
Accessories, General — Section 12 554 – 576
