Accessories
Operating Tools and Coding Keys 3
MCS MICRO 235
Coding keys
Operating tool Operating tool
with partially insulated shaft for male and female connectors for male headers
Type 1 equipped with CAGE CLAMP ®
3
Item No. Pack. Unit Item No. Pack. Unit Color Item No. Pack. Unit
Operating tool with partially insulated shaft, Operating tool with partially insulated shaft Coding key
type 1, (2.5 x 0.4) mm blade
210-719 1 233-335 1 white 733-330 100
black 733-331 100
(suitable for THR soldering)
Inserting conductor via (2.5 x 0.4) mm screwdriver. Inserting conductor via 233-335 operating tool. Snap-on coding key for headers.
Actuation perpendicular to conductor termination. Operation parallel to conductor entry.
