Accessories
6 Separators, Coding Keys and Coding Pins
472 MCS MIDI

Separators for group formation Coding keys Coding pins

for male headers for male headers for male headers for double-deck assembly,
to be snapped into lower level

Color Item No. Pack. Unit Color Item No. Pack. Unit Color Item No. Pack. Unit
Separator for headers, for group formation Coding keys for headers, Coding pin for male headers for double-deck
5/5.08 mm pin spacing assembly, snaps into lower level
light gray 231-500 200 (2 x 100) light gray 231-129 100 light gray 231-160 100

Coding keys for headers,
7.5/7.62 mm pin spacing
light gray 231-130 100

Separators for group formation are inserted directly into Snap-on coding key for male headers and CAGE Coding lower male header in combination with
the MCS MIDI Classic male headers. CLAMP -equipped male connectors. male header for double-deck assembly.
®
Group formation using separators means that at least The last pole of male and female connectors with 7.5 mm
1 pole is lost on the header. Female connectors with pin spacing has a width of 5 mm; for 7.62 mm pin
integrated end plates are available for formation of groups spacing, the pole width is 5.08 mm.
without loss of any poles for pin spacing of 5/5.08 mm. Always use a 231-129 coding key for coding this pole.
Formation of groups without the loss of any poles is
possible without using separators for pin spacing of
7.5/7.62 mm.
