2.7 Output Data

Pn mot
Inverter Output Maximum Maximum ADV200 - 4
(Recommended asyncronous motor rating, fsw = default)
Sizes Heavy Light Heavy Duty Light Duty output voltage output
ADV200-DC Duty Duty (150% overload) (110% overload) U2 frequency f2 IGBT braking unit
@ 400V @ 400V (1) (2) (3) (1) (2) (3) -4/4A -6/6A
[kVA] [kVA] [kW] [Hp] [Hp] [kW] [Hp] [Hp] [V] [Hz] [Hz]
3185 26,3 32 18,5 25 - 22 30 - -
3220 32 43 22 30 - 30 40 - -
4300 43 52 30 40 - 37 50 - - ADV200-DC
4370 52 60 37 50 - 45 60 - ADV200-...- -
4450 60 73 45 60 - 55 75 - 4/4A-DC: -
5550 73 104 55 75 - 75 100 - -
5750 104 125 75 100 - 90 125 - 0.98 x Uln 500 (6) -
5900 125 145 90 125 - 110 150 - ADV200-...- -
61100 145 173 110 150 - 132 175 - -
61320 173 208 132 175 - 160 200 - 6/6A-DC: - External optional ADV200 - 6
71600 208 267 160 200 150 200 250 200 0.95 x Uln 500 (6)
72000 267 319 200 250 200 250 300 250 (BUy series)
72500 319 409 250 300 250 315 400 350
73150 409 450 315 400 350 355 450 400 (Uln = AC input
73550 450 506 355 450 400 400 500 450 voltage from
400 kW 506 603 400 500 450 500 650 500 separate SM32
500 kW 603 776 500 650 550 630 850 700 or AFE200 power 200 (6) 200 (6) ADV100
630 kW 776 852 630 850 700 710 950 800 supply unit)
710 kW 852 956 710 950 800 800 1100 900
900 kW 1108 1247 900 1200 1000 1000 1300 1100
1 MW 1247 1420 1000 1300 1100 1200 1600 1300
1.35 MW - - - - 1500 - - 1600
1.65 MW - - - - 1800 - - 2000
(1) ADV200-...-4/4A-DC = @400 Vca; ADV200-...-6/6A-DC = @690 Vca. (2) ADV200-...-4/4A-DC = @460 Vca; (3) ADV200-...-6/6A-DC = @575 Vca. (6) See page 40 for details. ADV80
Rated output current In (fsw = default)
Sizes Heavy Duty Light Duty (110% overload)
ADV200-DC 150% overload (For Asynchronous motors) 160% overload (For Synchronous motors) (For Asynchronous motors) (For Synchronous motors)
@540 Vdc @650 Vdc @930 Vdc @1120Vdc @540 Vdc @650 Vdc @930 Vdc @1120Vdc @540 Vdc @650 Vdc @930 Vdc @1120Vdc @540 Vdc @650 Vdc @930 Vdc @1120Vdc
(-4/4A) (-4/4A) (-6/6A) (-6/6A) (-4/4A) (-4/4A) (-6/6A) (-6/6A) (-4/4A) (-4/4A) (-6/6A) (-6/6A) (-4/4A) (-4/4A) (-6/6A) (-6/6A)
[A] [A] [A] [A] [A] [A] [A] [A] [A] [A] [A] [A] [A] [A] [A] [A] AFE200
3185 38 34.2 - - 34 30.6 - - 46 41.4 - - 41 36.9 - -
3220 46 41.4 - - 41 36.9 - - 62 55.8 - - 56 50.4 - -
4300 62 55.8 - - 56 50.4 - - 75 67.5 - - 68 61.2 - -
4370 75 67.5 - - 68 61.2 - - 87 78.3 - - 78 70.2 - -
4450 87 78 - - 78 70.2 - - 105 94.5 - - 95 85.5 - -
5550 105 94.5 - - 95 85.5 - - 150 135 - - 135 121.5 - -
5750 150 135 - - 135 122 - - 180 162 - - 162 146 - - FFE200
5900 180 162 - - 162 146 - - 210 189 - - 189 170 - -
61100 210 189 - - 189 170 - - 250 225 - - 225 203 - -
61320 250 225 - - 225 203 - - 300 270 - - 270 243 - -
71600 300 270 170 148 (6) 270 243 153 182 (6) 385 347 210 133 347 312 189 164
72000 385 347 210 210 347 312 189 265 460 414 265 189 414 373 238 238
72500 460 414 265 233 414 373 238 290 590 531 330 209 521 469 297 261 SMB200
73150 590 531 330 291 521 469 297 330 650 585 375 261 585 527 337 296
73550 650 585 375 (5) 330 (5) 585 527 337 260 (5) 730 657 415 (5) 296 657 591 373 328
400 kW 730 657 400 400 657 591 360 500 870 783 500 360 783 705 450 450
500 kW 870 783 500 440 783 705 450 554 1120 1008 630 396 1008 907 567 499
630 kW 1120 1008 630 554 1008 907 567 625 1230 1107 710 499 1107 996 639 562
710 kW 1230 1107 710 (5) 625 (5) 1107 996 639 695 (5) 1380 1242 790 (5) 562 1242 1118 711 625
900 kW 1600 1440 900 792 1440 1296 810 880 1800 1620 1000 712 1620 1458 900 792
1 MW 1800 1620 1000 (5) 880 (5) 1620 1458 900 1012 (5) 2050 1845 1150 (5) 792 1845 1661 1035 911 PROGRAM.
1,35 MW - - 1300 (5) 1144 (5) - - 1170 (5) 1276 - - 1450 1029 - - 1305 1148
1,65 MW - - 1600 1408 - - 1440 1557 - - 1770 1267 - - 1593 1402
(1) Kv : Derating factor for DC-link voltage at 650 Vdc (5) Current values with an ambient temperature of 35°C.
(2) Kt : Derating factor with an ambient temperature of 50°C (1% every °C over 40°C with HD and 2% (6) If F switching = 2KHz, see column @930Vdc.
every °C over 40°C with LD) Note "@1120Vdc" column:
(3) Kf : Derating factor for higher switching frequency Derating value applied only at Ambient Temperature >30°C (If Ambient Temperature <=30°C
(4) Kalt : Derating factor with an ambient temperature of 50°C (1% every °C over 40°C with HD and 2% please select data indicated in "@1120VDC" column. APPENDIX
every °C over 40°C with LD). Value to be applied = 1.2% each 100 m increase above 1000 m.
For example: Altitude 2000 m, Kalt = 1.2% * 10 = 12% derating; In derated = (100 - 12) % =
88 % In
