Overload according to output frequency (Asynchronous motor control)
Overload HD (ADV200-...-DC-4/4A) Overload LD (ADV200-...-DC-4/4A)
200 120 ADV200 - 4
190 k2
180
170 110 k1
160
150
I out [%] 140 k1 k2 I out [%] 100
130
120
110 90
100
90 80
80 ADV200-DC
70 70
0 1 2 3 4 5 6 7 8 9 10 0 1 2 3 4 5 6 7 8 9 10
f [Hz] f [Hz]
_ _ Islow, .... Ifast; __ In _ _ Islow, .... Ifast; __ In
Overload HD (ADV200-...-DC-6/6A) Overload LD (ADV200-...-DC-6/6A)
200 120
190 k2
180 ADV200 - 6
170 110 k1
160 k3
150
I out [%] 140 k1 k2 I out [%] 100
130
120
110 90
100
90 80
80
70 70 ADV100
0 1 2 3 4 5 6 7 8 9 10 0 1 2 3 4 5 6 7 8 9 10
f [Hz] f [Hz]
_ _ Islow, .... Ifast; __ _ _ Islow, .... Ifast; __ In.
Synchronous motor control
Overload Derating according to switching frequency (HD) Overload according to ADV80
output frequency
Sizes
ADV200-DC HD HD LD
4/4A 160 % x In 200 % x In 110 % x In 2 kHz 4 kHz 6 kHz 8 kHz 10 kHz 12 kHz Heavy Duty Light Duty
(1’ every 5‘) (for 3’‘) (1’ every 5‘)
K1 HD K2 HD K3 HD K1 LD K2 LD
[a] [a] [a] [a] [a] [a] [a] [a] [a]
[%] [Hz] [Hz] [%] [Hz] AFE200
3185 54.4 68 50.6 34 34 28.9 23.8 20.4 17 100 5 8.3 85 5
3220 65.6 82 68.2 41 41 34.9 28.7 24.6 20.5 100 3 5 80 5
4300 89.6 112 82.5 56 56 47.6 39.2 33.6 28 100 3 5 80 3
4370 108.8 136 95.7 68 68 57.8 47.6 40.8 34 100 3 5 80 3
4450 124.8 156 115.5 78 78 66.3 54.6 n.a. n.a. 100 3 5 80 3 FFE200
5550 152 190 165 95 95 80.8 66.5 n.a. n.a. 100 3 5 85 5
5750 216 270 198 135 135 114.8 94.5 n.a. n.a. 100 5 8.3 85 5
5900 259.2 324 231 162 162 137.7 113.4 n.a. n.a. 100 5 8.3 85 5
61100 302.4 378 275 189 189 160.7 132.3 n.a. n.a. 100 3 5 100 3
61320 360 450 330 225 225 191.3 157.5 n.a. n.a. 100 3 5 100 3
71600 432 540 423.5 270 270 n.a. n.a. n.a. n.a. 100 3 5 80 3 SMB200
72000 555.2 694 506 347 347 n.a. n.a. n.a. n.a. 100 3 5 100 3
72500 662.4 828 649 414 351.9 n.a. n.a. n.a. n.a. 100 3 5 75 5
73150 833.6 1042 715 521 n.a. n.a. n.a. n.a. n.a. 100 3 5 100 3
73550 936 1170 803 585 n.a. n.a. n.a. n.a. n.a. 90 5 7.9 90 5
400 kW 1051.2 1314 957 657 657 (1) n.a. n.a. n.a. n.a. 100 3 5 100 3 PROGRAM.
500 kW 1252.8 1566 1232 783 665.6 (1) n.a. n.a. n.a. n.a. 100 3 5 75 5
630 kW 1612.8 2016 1353 1008 n.a. n.a. n.a. n.a. n.a. 100 3 5 100 3
710 kW 1771.2 2214 1518 1107 n.a. n.a. n.a. n.a. n.a. 90 5 7.9 90 5
900 kW 2304 2880 1980 1440 n.a. n.a. n.a. n.a. n.a. 100 3 5 100 3
APPENDIX
1 MW 2592 3240 2255 1620 n.a. n.a. n.a. n.a. n.a. 90 5 7.9 90 5
(1) from fw 6.03.
