Page 184 - Brass, Composite and Thermoplastic Fittings and Valves
P. 184
PTC Composite
PTC Composite
Parker’s PTC Fitting is a composite push-to-connect fitting that meets SAE and D.O.T. specifications.
Designed for all D.O.T truck and trailer applications, Parker PTC fittings reduce assembly time versus
compression style fittings .
Product Features:
■ Brass Collet
■ Buna N O-ring
■ Stainless Steel Tube Support
■ Meets D.O.T. FMVSS571.106
■ Meets SAE J2494-3
■ Composite Body – Strong, Lightweight,
Compact and Impact Resistant
■ Plug-in configurations
Markets: Applications:
■ Heavy Duty Truck ■ Air Brakes
■ Trailer ■ Air Tanks
■ Mobile ■ Air Ride
■ Sliders
■ Tire Inflation
■ Primary & Secondary
Air Lines
■ Cab Controls
Specifications:
Pressure Range Up to 250 psi
Temperature Range -40˚ to 200˚F
Compatible Tubing:
■ SAE J844 Type A & B nylon tubing
Parker Hannifin Corporation | Fluid System Connectors | Otsego, MI E6
