Page 310 - Brass, Composite and Thermoplastic Fittings and Valves

Catalog 3501E

Garden Hose Fittings Hose Nut Reducer 95GH L C HEX Hydraulic Quick Couplings/

High Flow Couplings
Applications
Parker Water Service Couplings are used anywhere
water hoses are connected and disconnected frequently.
PART NO.
L
They are used on a wide variety of applications
C HEX
HOSE THREAD
PIPE THREAD
including garden hoses, wash down systems, and
.63
1-1/8
1/8
95GH-12-2
3/4
mobile water tank lines. The unvalved design permits
maximum flow with minimum pressure drop.
L
Features
M
■ Brass and stainless steel construction
Hose Cap Nut 96GH for heavy duty service.
PART NO. HOSE THREAD L M
■ Durable 4-ball locking mechanism
96GH-12 3/4 .50 1.15 for secure connections.
■ Quality, temperature-resistant nitrile seals for a leak-free
L service life.
M D Specifications
Female Hose to Female ■ Body Size 3/4"
Pipe 98GH & 99GH C HEX
■ Rated Pressure (PSI) 200
PART HOSE PIPE C L M FLOW
NO. THREAD THREAD HEX DIA.D ■ Rated Flow (GPM) 28
98GH-12-8 3/4 1/2 1-3/16 1.14 1.01 .687 ■ Temperature Range (std seals) -40°F to +250°F
99GH-12-12 3/4 3/4 1-3/16 1.25 1.17 .750
L A

Swivel Connector Female M D High Flow Coupler C
Hose to Female Pipe 1163-60-BPD
98GHSV & 99GHSV C HEX
PART NO. BODY SIZE THREAD SIZE NH A C
PART HOSE PIPE C L M FLOW
NO. THREAD THREAD HEX DIA.D 1163-60-BPD 3/4 3/4-11 1/2 1.12 1.21
98GHSV-12-8 3/4 1/2 1 1.27 1.21 .687
99GHSV-12-12 3/4 3/4 1-3/16 1.34 1.21 .687
D
E
L
Swivel Nut Connector M D High Flow Nipple
101GHSV 1163-61-BPD
PART NO. HOSE THREAD L M FLOW DIA.D PART NO. BODY SIZE THREAD SIZE NH D E
101GHSV-12 3/4 1.25 1.15 .625 1163-61-BPD 3/4 3/4-11 1/2 1.25 .5

Rubber Garden Hose
Coupling Washer 901GH

PART NO. HOSE THREAD
901GH-12 3/4
NOTE: All female connector ends should have this rubber washer

Parker Hannifin Corporation | Fluid System Connectors | Otsego, MI J24
