Page 308 - Brass, Composite and Thermoplastic Fittings and Valves

Garden Hose Fittings

Garden Hose Fittings

Parker’s Garden Hose Fittings connect garden hose to other garden hose, to pipe or to tubing. Swivel
connections allow hose to twist without kinking.

Product Features:
■ All brass construction
■ 3/4” garden hose thread
■ Rubber washer
■ Flare, hose barb and pipe end configurations
■ High Flow couplings

Markets: Applications:
■ Industrial ■ Water Line
■ Mobile
■ Factory/process
automation

Specifications:
Pressure Range Up to 150 psi
Temperature Range +35˚ to +100˚F at 75 psi

Compatible Tubing:
■ Garden Hose

Note: 90Gh is intended for use with the 97HC hose clamp
or crimped ferrule. All female connector ends should
have a rubber washer(901GH-12) inserted prior to use.

Parker Hannifin Corporation | Fluid System Connectors | Otsego, MI J22
