Page 304 - Brass, Composite and Thermoplastic Fittings and Valves

Catalog 3501E

Metric Adapters 0904 Adapter Reducer Female

BSPP to Male BSPT
F
E
PART C1 C2 F L WT. 0907 Extended Adapter BSPP L WT.
C
PART
NO. BSPT BSPP MM MM KG BSPP MM MM MM KG
0904 10 13 R1/4 G1/8 14 16 .009 0907 00 10 G1/8 6 14 16 .009
0904 10 17 R3/8 G1/8 17 16.5 .020 0907 00 10 01 G1/8 6 14 36 .009
0904 13 17 R3/8 G1/4 17 16.5 .012 0907 00 13 G1/4 8 17 23 .020
0904 13 21 R1/2 G1/4 22 19.5 .038 0907 00 13 01 G1/4 8 17 43 .020
0904 17 21 R1/2 G3/8 22 19.5 .025
0904 17 27 R3/4 G3/8 27 23.5 .069
0904 21 27 R3/4 G1/2 27 23.5 .048

0920 Bulkhead BSPP and M5
C1 K T
PART BSPP C2 F F1 MAX L1 L2 MIN WT.
0905 Adapter Reducer Male NO. M5 METRIC MM MM MM MM MM MM KG
BSPP to Female BSPP or M5 0920 00 19 M5 M10X1 14 14 7 10.5 3.5 10.5 .013
C2
PART C1 BSPP E F L WT. 0920 00 10 G1/8 M16X1.5 19 22 9 14 4 16.5 .033
NO. BSPP M5 MM MM MM KG 0920 00 13 G1/4 M20X1.5 24 27 15 21 4 20.5 .057
0905 19 10 G1/8 M5 6 14 4.5 .009 0920 00 17 G3/8 M26X1.5 30 32 14 21 5 26.5 .096
0905 10 13 G1/4 G1/8 8 17 5 .009 0920 00 21 G1/2 M28X1.5 32 36 20 27 6 28.5 .117
0905 10 17 G3/8 G1/8 9 19 5 .020
0905 13 17 G3/8 G1/4 9 19 5 .012
0905 13 21 G1/2 G1/4 10 24 5.5 .038
0905 17 21 G1/2 G3/8 10 24 5.5 .025
0905 17 27 G3/4 G3/8 12 30 5.5 .069
0905 21 27 G3/4 G1/2 12 30 5.5 .048
0900 Male Straight Adapter BSPT
PART C1 C2 F L WT.
NO. BSPT BSPT MM MM KG
0900 00 10 R1/8 R1/8 12 19.5 .009
0900 10 13 R1/8 R1/4 14 23.5 .021
0900 00 13 R1/4 R1/4 14 27 .021
0900 10 17 R1/8 R3/8 17 24 .022
0906 Expander Female BSPP to Male BSPP
0900 13 17 R1/4 R3/8 17 27.5 .024
PART C1 C2 E1 E2 F L WT. 0900 00 17 R3/8 R3/8 17 28 .025
NO. BSPP/ BSPP MM MM MM MM KG
M5 0900 13 21 R1/4 R1/2 22 30.5 .045
0906 10 19 M5 G1/8 4 8 14 10 .009 0900 17 21 R3/8 R1/2 22 31 .045
0906 00 10 G1/8 G1/8 6 8.5 14 10 .009 0900 00 21 R1/2 R1/2 22 33.5 .055
0906 10 13 G1/8 G1/4 6 11.5 17 14 .020 0900 21 27 R1/2 R3/4 27 37.5 .084
0906 10 17 G1/8 G3/8 6 11.5 22 14.5 .038 0900 00 27 R3/4 R3/4 27 40 .092
0906 00 13 G1/4 G1/4 8 11.5 17 14 .040 0900 27 34 R3/4 R1 34 43 .143
0906 13 17 G1/4 G3/8 8 11.5 22 14.5 .042 0900 00 34 R1 R1 34 45.5 .156
0906 13 21 G1/4 G1/2 8 15 27 18 .061
0906 00 17 G3/8 G3/8 9 11.5 22 14.5 .061
0906 17 21 G3/8 G1/2 9 15 27 18 .062
0906 00 21 G1/2 G1/2 10 15 27 18 .070

Parker Hannifin Corporation | Fluid System Connectors | Otsego, MI J18
