Page 373 - Brass, Composite and Thermoplastic Fittings and Valves

Catalog 3501E

S T X e t S m E e t x n o i s n t i K
Bolt Ball Valves
P F r o u s e o n a r B s s B l l a V v l a e s
: 1 u r h t " 4 / 1 " 2 / 1 v v l a e s
1 Washer
: 2 u r h t " 4 / 3 " 1 v v l a e s
1 2 : 5 " 4 / 1 - 1 e e t x n o i s n e l n h t g
1 2 5
2 2 : 5 " 4 / 1 - 2 e e t x n o i s n e l n h t g
Stem
Extender
S T X e t S m E e t x n o i s n t i K
S S F r o u s e o n e l n i a t S s s e t S l e B l l a V v l a e s
: 1 u r h t " 4 / 1 " 2 / 1 v v l a e s
1 : 2 u r h t " 4 / 3 " 1 v v l a e s Stem
: 3 " 2 - " 4 / 1 - 1 v v l a e s Extender
Sleeve
1 2 : 5 " 4 / 1 - 1 e e t x n o i s n e l n h t g
1 2 5
2 2 : 5 " 4 / 1 - 2 e e t x n o i s n e l n h t g
All stem extension kit componentry is made from
high quality, corrosion resistant stainless steel Clip

Note: Stem extensions cannot be used
with series 509 and series 520.

Brass Valve Extension Dimensions STX-P-1-125 H L
D
PART VALVE B C H L M N FLOW
NO. SIZE HEX HEX Ø
STX-P-1-125 1/4 15/16 15/16 3.96 4.96 2.03 3.73 .375 N
STX-P-1-125 3/8 15/16 15/16 3.96 4.96 2.03 3.73 .375 B HEX
STX-P-1-125 1/2 1-1/16 1-1/16 3.96 5.05 2.20 3.84 .500
D
STX-P-2-125 3/4 1-1/4 1-5/16 3.96 5.25 2.42 4.06 .685
STX-P-2-125 1 1-1/2 1-9/16 3.96 5.89 2.75 4.33 .875 C HEX
M
Note: Drawing shows STX-P assembled to
XV500P series-not included

L
Brass Valve Extension Dimensions STX-P-1-225 H
PART VALVE B C H L M N D
NO. SIZE HEX HEX FLOW Ø
STX-P-1-225 1/4 15/16 15/16 3.96 4.96 2.03 4.73 .375 N
STX-P-1-225 3/8 15/16 15/16 3.96 4.96 2.03 4.73 .375
B HEX
STX-P-1-225 1/2 1-1/16 1-1/16 3.96 5.05 2.20 4.84 .500
STX-P-2-225 3/4 1-1/4 1-5/16 3.96 5.25 2.42 5.06 .685 D
STX-P-2-225 1 1-1/2 1-9/16 3.96 5.89 2.75 5.33 .875 C HEX
M
Note: Drawing shows STX-P assembled to
XV500P series-not included

Parker Hannifin Corporation | Fluid System Connectors | Otsego, MI K63
