polyflex ®
Catalog 4900
Hose and Fittings

Medium Pressure Tube Nipple B A

Y2
ØR

Part Connection Type A B R Maximum
Number Thread Size Overall Length Cutoff Allowance Diameter Working Pressure

inch mm inch mm inch mm psi MPa
6Y25X-16-12C 1" - 14 LH 5.48 139 2.75 70 1.69 43 20,000 137.9

Metric Female Swivel Fitting B A

C9

H

Part Connection Type A B H Maximum
Number Thread Size Overall Length Cutoff Allowance Hex Size Working Pressure

inch mm inch mm inch mm psi MPa
6C95X-25-12C M36 x 2 4.37 111 1.60 41 1.81 46 15,000 103.4

B98 Parker Hannifin Corporation
Parflex Division polyflex Operations
®
