Catalog 4900 polyflex ®
Hose and Fittings

2640N-24 polyflex Hose

Black Eagle TC

Part Jacket Minimum Maximum Maximum Minimum Minimum
Number Color I.D. O.D. Working Pressure Burst Pressure Bend Radius Weight

B
inch mm inch mm psi MPa psi MPa inch mm lbs/ft kg/m
2640N-24V80 Black 1.50 38 2.80 71 10,000 69.0 33,350 230.0 20.00 508 4.84 7.21

Construction: Polyamide core tube, high strength wire Temperature Range: -40°F and +140°F (-40°C and
reinforced and a polyurethane outer cover. +60°C). Contact polyflex for temperatures outside this
range.
Typical Applications: Flexible, chemical resistant alterna-
tive to steel pipe for high volume flow rate pumping
offshore, oilfield well service cementing, chemical injection
and gas transfer. For use in high pressure hydraulic
systems, and as large volume waterblast delivery hose to
distribution manifolds for multiple work stations.

National Pipe Tapered (NPT) Male Fit- B A

ting
01

ØR

Part Connection Type A B R Maximum
Number Thread Size Overall Length Cutoff Allowance Diameter Working Pressure

inch mm inch mm inch mm psi MPa
6015X-32-24-TC 2" NPT 9.08 231 4.20 107 3.35 85 10,000 69.0

B99 Parker Hannifin Corporation
Parflex Division polyflex Operations
®
