Catalog PDN1000-3US Actuator Products – Rodless CylindersProducts – Rodless Cylinders
OSP-P SeriesSeries – accessories
Parker Pneumatic OSP-P
adaptor profile, ø 16-50 mm

adaptor profile OSP
A universal attachment for moun ting of valves etc.
Solid material
Order number
Series Standard Stainless
OSP-P16 20432Fil 20438Fil
OSP-P25 20006Fil 20186Fil
OSP-P32 20006Fil 20186Fil
OSP-P40 20025Fil 20267Fil
OSP-P50 20025Fil 20267Fil
B

t-Slot Profile ø 16-50 mm

t-slot profile OSP
A universal attachment for mounting with standard T-Nuts Rodless Cylinders Actuator Products
Order number
Series Standard Stainless
OSP-P16 20433Fil 20439Fil
OSP-P25 20007Fil 20187Fil
OSP-P32 20007Fil 20187Fil
OSP-P40 20026Fil 20268Fil Combination of Series OSP-P with system profiles OSP-P Series
OSP-P50 20026Fil 20268Fil
Note: Can be used in conjunction with IPS T-nut (20-058).

Connection profile, ø 16-50 mm P1X Series

For combining
Series OSP-P with system profiles
P1Z Series
Series OSP-P with Series OSP-P
Order
Series number
OSP-P16 20849Fil
OSP-P25 20850Fil GDL Series
OSP-P32 20850Fil
Combination of Series OSP-P with Series OSP-P
OSP-P40 20851Fil
OSP-P50 20851Fil

B231 Parker Hannifin Corporation
Pneumatic Division
Richland, Michigan
www.parker.com/pneumatics
