Parker Pneumatic P5GU Clean Room Harsh Environment Series

Dimensions: P5GU Clean Room Harsh Environment Series

Unless otherwise noted all tolerances are as shown below
A
C
Dimensions are Third Angle
symmetrical about Projection
centerline
L C F E

L C
U (2 Places) T (4 Places)
Open
D1 D L
L C L C
M
K K1
G
J H B
X (Sensor
V - Air Ports Closed Mounting Hole.
(2 Places) Metric (mm)
Do Not Exceed (0.) = (±.25)
W - Purge or B1 Open Depth) (0.0) = (±.13)
Scavenge Port B Closed (0.00) = (±.013)
N S (4 Places)
L C Automation Products Actuator Products
P L C
Q R

Jaw Mounting Pattern
(Shown In Open Position)

Grippers

Part number A B B1 C D D1 E F G H J K K1 L M N P Q R
P5GU-011(006) 48.3 38 44 19.1 8 6 19.1 15.09 17 29.5 27.8 13 11 11 8 6.4 5.69 +.003 19.1 6.4
-.003
P5GU-011(013) 62.9 46 59 19.1 13 6 19.0 15.09 17 29.5 27.8 13 11 16 8 8.3 5.69 +.003 23.2 6.4 Slide Tables
-.003
+.003
P5GU-013(019) 83.4 63 83 25.4 14 15 22.2 16.66 18 32.6 30.3 13 11 19 8 12.7 5.69 -.003 31.8 6.4
P5GU-013(025) 101.8 76 101 25.4 14 24 22.2 16.66 18 32.6 30.3 13 11 25 8 15.9 5.69 +.003 38.1 6.4
-.003
Rotary Tables
Part number S T U V W X
P5GU-011(006) M3 x 4 Dp M3 x 4 Dp Ø 3 SF x 4 Dp M5 M5 M3 x 3 Dp
P5GU-011(013) M3 x 4 Dp M3 x 4 Dp Ø 3 SF x 4 Dp M5 M5 M3 x 4 Dp
P5GU-013(019) M3 x 4 Dp M3 x 8 Dp Ø 3 SF x 6 Dp M5 M5 M3 x 4 Dp
Escapements
P5GU-013(025) M3 x 4 Dp M3 x 8 Dp Ø 3 SF x 6 Dp M5 M5 M3 x 4 Dp
Dimensions in millimeters

Sensors

Fittings
