Test Plug Modules for Terminal Strips without Push-Button
8 260, 261 and 262 Series
416
Suitable for 260 Series Suitable for 261 Series (also 264 Series) Suitable for 262 Series
Test voltage 250 V/500 V 1 2 Test voltage 400 V/800 V 1 2 Test voltage 500 V/800 V 1 2
Test current 0.5 A/6 A 3 Test current 0.5 A/6 A 3 Test current 0.5 A/6 A 3
Average contact pressure 2.2 N per pin Average contact pressure 2.2 N per pin Average contact pressure 2.2 N per pin

Pack. Pack. Pack.
Item No. Item No. Item No.
Unit Unit Unit
Test plug module without locking levers, Test plug module without locking levers, Test plug module without locking levers,
can be snapped together, module width 5 mm, can be snapped together, module width 6 mm, can be snapped together, module width 7 mm,
for 2-conductor terminal blocks for 2-conductor terminal blocks for 2-conductor terminal blocks
gray 249-135 100 (4x25) gray 249-136 100 (4x25) gray 249-137 100 (4x25)
Test plug module without locking levers, Test plug module without locking levers, Test plug module without locking levers,
can be snapped together, module width 8 mm, can be snapped together, module width 10 mm, can be snapped together, module width 12 mm,
for 4-conductor terminal blocks for 4-conductor terminal blocks for 4-conductor terminal blocks
gray 249-138 100 (4x25) gray 249-139 100 (4x25) gray 249-140 100 (4x25)
Test plug module with locking levers, Test plug module with locking levers,
can be snapped together, module width 5 mm, can be snapped together, module width 6 mm,
for 2-conductor terminal blocks for 2-conductor terminal blocks
gray 260-404 100 (4x25) gray 261-404 100 (4x25)

Test plug module with locking levers, Test plug module with locking levers,
can be snapped together, module width 8 mm, can be snapped together, module width 10 mm,
for 4-conductor terminal blocks for 4-conductor terminal blocks
gray 260-405 100 (4x25) gray 261-405 100 (4x25)

Accessories for Test Plug Modules

Test plug,
with 500 mm cable,
2 mm Ø
red 210-136 50
Test plug,
with 500 mm cable,
2.3 mm Ø
yellow 210-137 50
