Mounting Carrier
222 Series 12
505
Mounting carrier Strain relief plate Angled DIN-rail adapter
52 mm/2.04 in
26 mm/ 1.03 in 21,5 mm/ 0.85 in
66 mm/2.6 in 67,5 mm/2.66 in 42 mm/1.65 in
Pack. Pack. Pack.
Color Item No. Color Item No. Color Item No.
Unit Unit Unit
Mounting carrier, 22 mm wide, Strain relief plate, 4 mm thick, Angled DIN-rail adapter, 18.5 mm wide,
for 2-, 3-, 5-conductor compact splicing connectors for snap-on fixing to 222-500 mounting carrier in combination with 222-500 mounting carrier for DIN 35
rail mounting
orange 222-500 50 (5x10) orange 222-505 50 (5x10) gray 222-510 50 (5x10)
Item-Specific Accessories
Self-adhesive marking strips, plain,
Height of marking strip: 5 mm, 48 self-ad-
hesive strips per card
white 210-334 1
