P. 5
Linear Tritex 2) Move To A Preset Force • Alternate Mode; allows you
• 2 and 3 inch (51 and 76 mm) Or Torque to switch between 2 operating
frame sizes The Tritex Series al- modes.
• 3 to 18 inch (75 to lows you to terminate Selectable Output Functions
455 mm) strokes available your move upon the Enabled • Homed • Ready
• 0.1, 0.2, 0.4 and 0.5 inch achievement of a pro- (Enabled and Homed) • Fault •
lead (2.54, 5.08, 10.16 and grammed torque or Warning • Fault or Warning Ac-
12.7 mm) planetary roller force. This is an ideal tive • Move (1-4) in Progress •
screws mode for pressing and Homing • Jogging • Jogging+ •
• Up to 1250 lbf (5560 N) max clamping applications. Jogging- • Motion • In Position
continuous thrust capacity, • At Home Position • At Move
2270 lbf (10,000N) peak 3) Position Propor- (1-4) • Position • Stopped •
• Up to 33 inches (838 mm) tional To An Analog Holding • In Current Limit •
per second max linear Signal In Current Fold back • Above
velocity Ideal for process control Rated Current • Maintain a
• IP54 sealing standard, IP65 solutions, the Tritex Preset Force • Home
optional Series provides the func-
• Multiple mounting options tionality to position Analog Input: 0 to +10 VDC
a control valve by or 4-20mA, 12 bit resolution
Tritex Series Operation following an analog input • Force/torque • velocity • posi-
The Tritex Series actuators signal. This allows the tion
can operate in one of fi ve Tritex Series to deliver Analog Output: 4-20mA,11 bit
different motion producing precise valve control resolution
modes. These modes solve unachievable by other • Force/torque • velocity • posi-
an endless variety of applica- electric, hydraulic or tion
tions in industrial automation, pneumatic actuators.
medical equipment, fasten- Serial Interface: RS485,
ing and joining, blow mold- 4) Velocity Proportional to An Modbus RTU
ing, injection molding, testing, Analog Signal • Programming • controlling •
food processing, and more. Tritex actuators offer you the
capability to control velocity with monitoring
Programmed functions are an analog signal. This is par-
stored in the Tritex non-vola- ticularly useful with Tritex rotary Custom Products
tile memory. An RS/485 serial actuators offering precise con- While Exlar delivers Tritex
interface allows control, pro- trol of the speed of any process actuators off the shelf, Exlar
gramming and monitoring of all or operation. prides itself in its ability to
aspects of the motor or actua- modify the products thereby
tor as it performs your applica- 5) Force/Torque Proportional fulfi lling your exact needs and
tion. to Analog Signal assuring the success of your
Perfect for pressing and torqu- application.
Operating Modes ing applications, you can control
torque from an analog input. Exlar also welcomes the op-
1) Move To A Position (Or portunity to work with you
Switch) Communications & I/O to develop custom software
The Tritex Series actuators al- pages tailored to your applica-
low you to execute your pro- Digital I/O: 8 input, 4 output, tion needs. Customer logos,
grammed positions or distanc- 10-24 VDC, optically isolated specialty control pages and
es. You may also use a limit pre-confi gured setups are just
switch or other input device as Selectable Input Functions some of the software tools that
the end condition of a move. Enable • Initiate Move (1-4) • we can provide to make Tritex
This combination of index fl ex- Dedicated Position • Jog+ • Jog- products a perfect fi t for your
ibility provides a simple solution • Jog Fast • Home • Extend application.
for point-to-point indexing. Switch • Retract Switch • Home
Switch • Teach Enable • Teach Contact Exlar at (952) 368-
Move (1-4) • Stop • Hold 3434 or info@exlar.com to
discuss the details.
5
