2002 Series


      Vertical Hold Down Clamps | Product Overview


      Features:                                        Applications:         Also Available:
      • Large hand clearance for improved safety       • Checking fixtures   See page MC-ACC-1 for accessories
      • Bolt pattern interchangeable with 202 Series   • Assembly & test     Accepts M6 or 1/4 spindle accessories
      • Three times the holding capacity of 202 Series  • Light machining
      • Hardened bushings at key pivot points          • Woodworking
      • Near vertical clamping contact
      • BLK models feature a black, non-reflective finish

        Covered under one or more U.S./International Patents



      2002-U                2002-U-LS-BLK        2002-S               2002-UB               2002-UB-LS-BLK
      Flanged               Blackout Series       Flanged Base         Straight Base         Blackout Series
      Base                  Flanged Base          Solid Bar            U-Bar                 Straight Base
      U-Bar                 U-Bar                                                            U-Bar









      2002-SB               2002-UR               2002-SR             2002-UBR              2002-SBR
      Straight Base         Flanged Base          Flanged Base         Straight Base         Straight Base
      Solid Bar             U-Bar                 Solid Bar            U-Bar                 Solid Bar
                            with                  with                 with                  with
                            DESTACO ®             DESTACO ®            DESTACO ®             DESTACO ®
                            Toggle Lock           Toggle Lock          Toggle Lock           Toggle Lock
                            Plus                  Plus                 Plus                  Plus





      2002-U207             2002-UR207
      Flanged Base          Flanged Base
      U-Bar                 U-Bar
      Interchangeable       Interchangeable
      with 207 Series       with 207 Series,
                            DESTACO
                                    ®
                            Toggle
                            Lock Plus



       This item is available upon request




















                                         MC-VHD-3                Dimensions and technical information are subject to change without notice
