PRODUCT DATA SHEET ROV INTERVENTION TOOLING
15KW SURFACE HYDRAULIC POWER UNIT
Technical Specifications
General
Size 990 mm x 990 mm x 1460 mm (l x w x h)
Weight in Air (Dry) 297 kg (655 lb)
Weight in Air (Full of Oil) 427 kg (941 lb)
Design Life 10 years (with regular maintenance)
Tool Supply or Specification
Electric Motor Voltage 440 VAC at 50 Hz 4-Pole
Electric Motor Current (Full Load) 26 Amps
Electric Motor Rating 15 kW
Hydraulic Tank Capacity 130 Litres
Hydraulic Operating Fluid Hydraulic Oil – ISO 32
Hydraulic Pump Displacement 28 cc/rev, (1.71 in³/rev)
Hydraulic Filters Pressure Side: 10 micron
Tank Side: 10 micron
Tool Output (MROV HPU)
Maximum Continuous Hydraulic Pressure 205 barg, (3000 psig)
Maximum Back Pressure 30 barg, (430 psig)
Maximum Output Hydraulic Flow 30 l/m, (7.9 g/m)
Key Features
Self-contained unit with compact and portable design
Variable output pressure and flow rate
Hydraulics viewable via level gauge
Integral hydraulic filters
Reliable performance
Stainless Steel frame construction
