PROGRAMMABLE MOTION CONTROL SYSTEMS  735
                             calculated and commanded. In this case, the feedrate acts as the master (although it is not
                             an axis), and all of the motion axes are slaved to it. Another alternative is to select one
                             of the axis as master and define its motion, then derive the desired motion of other axes so
                             that the tool traces the desired path. CNC machine tools are an example of the coordinated
                             motion control application where contour coordination is most commonly implemented.
                                  Consider a two-axis motion control application where the two axes are required to
                             trace a contour, that is an XY stage holding a tool, and the tool is required to trace a path
                             in x-y plane. Gearing coordination would generate a path that is a straight line. Contouring
                             is a more general form of coordination and requires the ability to trace any path in the
                             motion space.
                                  The path can be defined as function of:
                                1. Time, each axis motion is separately defined as a function of time to generate the
                                  path.
                                2. One axis is set as master and its motion for the path is defined, the other axis’ motion
                                  is set as a function of the master axis position.
                                3. Path length or speed parameter – each axis motion is defined in terms of a path
                                  parameter.

                             CNC Programming       Computer numeric control (CNC) programming is a program-
                             ming language used to define the motion of machine tools. The most common CNC
                             language in use today is the G-code. The G-code standard is defined by the Electronics
                             Industry Association (EIA) standard 274-D. Although this standard exists, there are minor
                             variations in the implementation of G-code from one manufacturer to another. The meaning
                             of some codes also varies from one machine tool type to another. For example, G70 code
                             means programming in units of inches in machining centers, whereas the same G70 code
                             means edge finding in electric discharge machines (EDM).


                             10.5.4 Sensor Based Real-time Coordinated Motion
                             As the sophistication of computer controlled machines increases, the type of motion
                             demands placed on them becomes more and more complicated. Particularly in robotic
                             manipulator applications, the desired motion may not be known in advance. The machine
                             is required to sense its environment (i.e., using vision systems), and decide on a motion
                             strategy and generate the motion command profiles for each individual axis. The motion
                             synchronization used may be different for different phases of its motion. Furthermore, this
                             decision as to what kind of strategy to use is determined online by the control software.
                             Interpretation of sensory data, and generating intelligent motion planning strategies not
                             planned in advance, is one of the current challenges of programmable motion control in
                             robotics devices.


                      10.6 COORDINATED MOTION APPLICATIONS

                             10.6.1 Web Handling with Registration Mark

                             The following applications have very similar motion coordination requirements
                             (Figures 10.12, 10.13):

                                1. rotating cutting knife to cut a web (i.e., paper, plastic) to a fixed length,
                                2. rotating printing head to print over a web,
                                3. rotating sealing head to seal a web or bag.
