Truckline

Impact Wrench 1” 2450 Nm DG 2425/2426

• The 3-phase torque adjustment and the clockwise and anticlock-
wise rotation occur at the push of one button situatued on the back
of the engine cover.
• Exhaust air flow
Art. No. 5350 2426:
• Sspindle length = 150 mm

Technical Data
Torque: 2450 Nm
Drive: 1”
Working pressure: 6.3 bar
Air consumption: 370 l/min.
Sound Level (LpA): 88.4 dB(A)
Vibration: 7.2 m/s²
Weight: 11.5 kg
Recommended hose-Ø: 13 mm
Air connection: 1/2” lG
Suitable plug nipple: 3926 12 3

Article No. Article Description QTY
5350 2425 1"IMPACT WRENCH 2425 1
5350 2426 1"IMPACT WR.LONG SPINDLE 2426 1

Impact wrench 1” 2900 Nm

• high performance impact wrench with metal housing
• runs right -left with the current 3-level torque setting
• very robust and almost maintenance-free due to closed hammer
system
art. no. 5350 2476:
• spindle length= 204 mm

Technical Data
art. no. 5350 2466 5350 2476
max torque: 2900 Nm 2900 Nm
square drive: 1” 1”
operating pressure: 6.3 bar 6.3 bar
continuous air consumption: 1130 l/min. 1130 l/min
average air consumption: 370 l/min. 370 l/min
sound level (LpA): 100 dB(A) 100 dB(A)
vibration: 6.5 m/s² 7.8 m/s²
weight / total length: 10.6 kg/360 mm 10.6 kg/510 mm
recommended hose-Ø: 13 mm 13 mm
air connection: 1/2” IG 1/2” IG
suitable male coupling: art. no. 3926 12 8 art. no. 3926 12 8

Article No. Article Description QTY
5350 2466 1"IMPACT WRENCH 2466 1
5350 2476 1"IMPACT WR.LONG SPINDLE 2476 1

Technical data subject to change.
