Truckline

Impact Wrench 3/4” 1424 Nm DG 2551

• 2-phase power control (2 forward / 2 backwards)
• Outlet support due to handle

Technical Data
Max. torque: 1,424 Nm
Working torque: 1,085 Nm
Square drive: 3/4”
Working pressure: 6.3 bar
Coninuous air consumption: 852 l/min
Average air consumption: 228 l/min
Sound level (LpA): 96.5 dB(A)
Vibration: 6.4 m/s²
Weight: 4.0 kg
Recommended hose-Ø: 13 mm
Air connection: 3/8” IG
Suitable plug nipple: Art.-No. 3926 38 3

Article No. Article Description QTY
5350 2551 3/4"IMPACT WRENCH IR259 1

Impact Wrench 1” 2200 Nm DG 2190/2190 6

• The titanium hammer case reduces the weight and extends the ser-
vice life at the same time
• Lower weight: approx. 50% lower than other 1” impact wrenches
• High power and speed with 2200 Nm and 6800 1/min
• Modern handle design which enables a professional use and easy
working
• Makes work easier, less expenditure of force for e.g. shoulders,
arms
Art. No. 5350 2190 6:
• Spindle length = 152 mm

Technical Data
Art. No. 5350 2190 5350 2190 6
Max. torque: 2,200 Nm 2,200 Nm
Working torque: 200 – 1,630 Nm 200 – 1,630 Nm
Square drive: 1” 1”
Working pressure: 6.3 bar 6.3 bar
Air consumption: 1,644 l/min 1,644 l/min
Sound level (LpA): 336 l/min 336 l/min
Vibration: 103.8 dB(A) 103.8 dB(A)
Weight/total length: 8.3 m/s² 9.8 m/s²
Recomm. hose-Ø: 6.3 kg / 386 mm 7.0 kg / 546 mm
Air connection: 13 mm 13 mm
Recomm. max screw size: 1/2” IG 1/2” IG
Suitable plug nipple: M32 M32
Art.-No. 3926 12 8 Art.-No. 3926 12 8

Article No. Article Description QTY
5350 2190 1"IMPACT WRENCH IR 2190TI 1
5350 2190 6 1"IMPACT WRENCH LONG IR 2190-6 1

Technical data subject to change.
