HYDERABAD DIVISION - LOAD TABLE FOR GOODS TRAIN (ELECTRIC)

                                                     SECTION                                     LOAD                         WAG 5             WAG 7             WAG 9
                                                                                                                                                                                              Remarks
                                                                           UP DIR                                           SH       MU       SH       MU        SH      MU


                                         MLY/Cabin-MJF-STPD-FM                          42BCNL/42BCNAL                      NP        P       NP         P       P#*       P       * Not to stop at H/S of FM,
                                                                                                                                                                                                  MJF
                                         (Distance:  22KM, Ruling                     58 BCNHL/59 BOXNL                     NP       NP       NP         P       NP        P

                                         Gradient 1/150,                                                                                                                          # Banker to be given during

                                         LL Capacity 686 meters)                    45 BOST/45 CONCORD/                     NP        P       NP         P       NP        P
                                                                                   43 BRN/50 BTPNL/45 BLC                                                                               inclement weather.




                                         FM-STPD-MJF-MLY/Cabin                          42BCNL/42BCNAL                      NP        P                  P        P        P

                                         (Distance: 22 KM, Ruling                     58 BCNHL/59 BOXNL                     NP       NP       NP         P                 P
                                         Gradient 1/150,
                                         LL Capacity 686 meters)                    45 BOST/45 CONCORD/
                                                                                   43 BRN/50 BTPNL/45 BLC

                                                                                                      Note: P-permitted, NP- not permitted


                                         1) In addition to trailing loads mentioned, BV is also permitted.
                                         2) In case of stalling the driver should not indefinitely try to pull the load thus causing wheel slip and damage to rail. Instead ask
                                         for relief/banker engine

                                         3)  If stalling takes place on account of not following the above conditions failure/ detention / punctuality loss to coaching trains
                                         shall not be shown on loco account.

                                         4) SH of any class of any loco can take full length empty train of any stock.
                                         5) In case of inclement weather and CD of SR 30 kmph and below is imposed at the foot/peak of gradient, banker to be
                                         provided where frequent stalling occurs.

                                         6) SH of any class of any Loco can take full length of empty train.

                                         7) Load table is prepared for standard composition rakes
                                         A) for BCN/BCNA-42, B)BCNHL-58, C)BOXN/BOXNHL-59, D)BOST/CONCORD-45, E)BRN-43, F)BTPN-50& G)BLC-45
