Examples of simplifying Boolean expression using De Morgan’s theorem
Method 1: Breaking the long bar
A BC
Breaking long bar changes ORing (+) to ANDing
A BC
Applying Complement law A A to BC
ABC
So, A reduces/simplifies to ABC
BC
Method 2: Breaking the short bar first
A BC
Breaking the shortest bar changes ORing to ANDing
A (B ) Applying the associative property to remove parenthesis
st
A B C Breaking the long bar into two places between 1 and 2nd terms
A B C and between 2nd and 3rd terms
ABC
