Page 1607 - Master Catalog 2017, Inch

Hole Finishing
™
HSR Application Data • Series 450281

™
„ Series 450281 • Coated • Carbide-Tipped • Helical Flute • Grade K10F-DCFD • Inch

Cutting Speed — vc
Recommended Feed Rate per Rev
Range — SFM
Material Tool
Group min max Diameter 0.5–0.590 0.590–0.787 0.787–1.181
1 360 – 420 IPR 0.020–0.035 0.024–0.041 0.024–0.043
2 340 – 410 IPR 0.020–0.035 0.024–0.041 0.024–0.043
3 310 – 380 IPR 0.020–0.035 0.024–0.041 0.024–0.043
P
4 200 – 260 IPR 0.020–0.035 0.024–0.041 0.024–0.043
5 100 – 160 IPR 0.020–0.035 0.024–0.041 0.024–0.043
6 100 – 130 IPR 0.014–0.026 0.016–0.031 0.020–0.035
1 100 – 130 IPR 0.014–0.026 0.016–0.031 0.020–0.035
M 2 100 – 130 IPR 0.014–0.026 0.016–0.031 0.020–0.035
3 70 – 100 IPR 0.014–0.026 0.016–0.031 0.020–0.035
1 250 – 310 IPR 0.024–0.047 0.028–0.051 0.031–0.055
K 2 250 – 310 IPR 0.024–0.047 0.028–0.051 0.031–0.055
3 230 – 290 IPR 0.024–0.047 0.028–0.051 0.031–0.055
1 100 – 130 IPR 0.012–0.020 0.012–0.024 0.014–0.026
S
2 70 – 100 IPR 0.012–0.020 0.012–0.024 0.014–0.026

Hole Finishing

widia.com U29
