Cahyo Wibowo / JOJAPS – JOURNAL ONLINE JARINGAN PENGAJIAN SENI BINA
MATERIAL AND RESEARCH METHODS
Materials Research
The material / material used is Natural Gas which has been compressed into a CNG tube with a pressure of 250 bar with a total
volume of gas used 200 Nm3.
Tools and Instruments
The tools used for measuring flow rate are as follows:
Stopwatch / Timekeeper
Figure 2. Stopwatch, as a timekeeper
Pressure Gauge as a gas pressure gauge at each stage
Figure 3. Pressure Gauge, as a gas pressure gauge at each stage
Thermometer to measure gas temperature
Figure 4. Thermometer Gauge
Flow meter to measure mass flow rates.
Figure 5. Coriolis Flow-meter Endress Hauser
CNG gas tube, for storing pressurized gas.
