COPPER COMPRESSION LUGS

TYPE BLY

Standard Barrel - One Hole with Inspection Window
• Manufactured from high conductivity seamless copper tubing
• Tin-plated to inhibit corrosion
• Beveled entry for easy cable insertion
• Inspection window insures full cable insertion
• Rounded Tongue accomodates full washer clearance

BLY DIMENSIONS & INDEX REFERENCE

FIGURE DIMENSIONS (IN.) INSTALLATION TOOLING

COPPER STUD TONGUE TONGUE TONGUE BARREL OVERALL MECHANICAL HYDRAULIC T&B WIRE
CONDUCTOR HOLE PENN-UNION DIELESS
CATALOG NO. SIZE WIDTH LENGTH THICKNESS LENGTH LENGTH BURNDY MECHANICAL TOOL DIE BURNDY DIE MS90485- STRIP
SIZE
BLY10-T7 • + “W” “C” “T” “B” “L” INDEX Y35+ Y39 DIE CAT. NO. DIE MS90485- LENGTH

BLY10-L36 • + 10 STR #4-#6 0.32 0.40 0.08 0.44 0.96 Y8MRBI - -- - - 7/16”
12 SOL #8-#10 0.31 0.36 0.08 0.38 0.80 MR8G98 TDM-250XF
BLY8C-L14 Y10D Y14MV TDM-250XF
BLY8C-L TDM-250XF
BLY8C-L1 #8 0.42 0.47 0.08 0.37 1.15 TDM-250XF
BLY8C-L2
BLY8C-L3 8 #10 0.42 0.47 0.08 0.37 1.15 UV8L Nest
BLY8C-L4
BLY6C-L1 Aircraft 1/4” 0.42 0.51 0.08 0.37 1.22 Non-Ratchet: 38 Y34PLA 11781M -8 1/2”
BLY6C-L Indentor
BLY6C-L4 AN 8 5/16” 0.59 0.71 0.08 0.50 1.30 MY29-11
BLY6C-L2
BLY6C-L10 8 AWG 3/8” 0.59 0.71 0.08 0.50 1.30 (1) Crimp
BLY4C-L3
BLY4C-L 1/2” 0.83 0.88 0.08 0.50 1.55
BLY4C-L4
BLY4C-L2 6 #10 0.47 0.54 0.08 0.39 1.31 UV6L Nest
BLY4C-L5 Aircraft
BLY2C-L3 1/4” 0.47 0.54 0.08 0.39 1.31 Non-Ratchet: 39 Y34PLA 11782M -6 1/2”
BLY2C-L1 AN 6 5/16” 0.62 0.67 0.08 0.45 1.44 MY29-11 Identor 1/2”
BLY2C-L2 6 AWG 3/8” 0.62 0.67 0.08 0.50 1.44 5/8”
BLY2C-L (1) Crimp
BLY2C-L4 1/2” 0.83 0.88 0.08 0.50 1.68

4 #10 0.63 0.58 0.10 0.45 1.40 UV4L Nest
Aircraft
1/4” 0.63 0.58 0.10 0.45 1.40 Non-Ratchet: 40 Y34PLA 11783M -4
AN 4 5/16” 0.63 0.66 0.10 0.50 1.49 MY29-11 Indentor
4 AWG 3/8” 0.65 0.66 0.10 0.50 1.49
(1) Crimp
1/2” 0.83 0.88 0.10 0.50 1.72

2 #10 0.71 0.75 0.11 0.63 1.73 UV2L Nest
Aircraft
1/4” 0.71 0.75 0.11 0.63 1.73 Non-Ratchet: 41 Y34PLA 11784M -2
AN 2 5/16” 0.71 0.75 0.11 0.63 1.73 MY29-11 Indentor
2 AWG 3/8” 0.71 0.75 0.11 0.63 1.73
(1) Crimp
1/2” 0.80 0.90 0.11 0.63 1.90

40
