BLY DIMENSIONS & INDEX REFERENCE (CONTINUED)

FIGURE DIMENSIONS (IN.) INSTALLATION TOOLING

COPPER STUD TONGUE TONGUE TONGUE BARREL OVERALL MECHANICAL HYDRAULIC T&B WIRE
CONDUCTOR HOLE PENN-UNION DIELESS
CATALOG NO. SIZE WIDTH LENGTH THICKNESS LENGTH LENGTH BURNDY MECHANICAL TOOL DIE BURNDY DIE MS90485- STRIP
SIZE
BLY1C-L6 #10 “W” “C” “T” “B” “L” INDEX Y35+ Y39 DIE CAT. NO. DIE MS90485- LENGTH
BLY1C-L1 1 1/4”
BLY1C-L2 Aircraft 5/16” 0.77 0.72 0.13 0.62 1.67 UV1CL Nest
BLY1C-L 3/8” 0.77 0.83 0.13 0.62 1.85
BLY1C-L3 AN 1 1/2” 0.77 0.83 0.13 0.62 1.85 Non-Ratchet: TDM-250XF 42 Y34PLA 11785M -1 5/8”
BLY1C-L4 1 AWG 7/16” 0.77 0.83 0.13 0.62 1.85 MY29-11 Indentor
BLY25-L1 1/4” 0.77 0.95 0.13 0.62 1.98
BLY25-L2 1/0 5/16” 0.77 0.83 0.13 0.62 1.85 (1) Crimp
BLY25-L Aircraft 3/8” 0.85 0.93 0.13 0.68 2.05
BLY25-L3 AN 1/0 1/2” 0.85 0.93 0.13 0.68 2.05 UV25L Nest
BLY25-L4 1/0 AWG 5/8” 0.85 0.93 0.13 0.68 2.05
BLY25-L6 7/16” 0.85 1.01 0.13 0.68 2.09 Non-Ratchet: TDM-250XF 43 Y34PLA 11786M -01 11/16”
BLY26-L1 2/0 1/4” 0.90 1.16 0.13 0.68 2.31 MY29-11 Indentor
BLY26-L2 Aircraft 5/16” 0.85 0.93 0.13 0.68 2.05
BLY26-L AN 2/0 3/8” 0.94 1.05 0.13 0.81 2.32 (1) Crimp
BLY26-L3 2/0 AWG 1/2” 0.94 1.05 0.13 0.81 2.32
BLY26-L12 5/8” 0.94 1.05 0.13 0.81 2.32 Non-Ratchet: TDM-250XF - - 11787M -02 13/16”
BLY26-L4 3/0 7/16” 0.94 1.05 0.13 0.81 2.32 MY29-11
BLY27-L Aircraft 3/8” 0.94 1.28 0.13 0.81 2.54
BLY27-L1 AN 3/0 1/2” 0.94 1.05 0.13 0.81 2.32 Non-Ratchet: TDM-250XF - - 11788M -03 13/16”
BLY27-15 3/0 AWG 5/8” 1.05 1.09 0.14 0.81 2.46 MY29-11
BLY27-L3 + 1/4” 1.05 1.09 0.14 0.81 2.46
BLY27-L2 4/0 5/16” 1.05 1.28 0.14 0.81 2.63 Non-Ratchet: TDM-250XF - - 11789M -04 7/8”
BLY27-6 Aircraft 7/16” 1.05 1.09 0.14 0.81 2.46 MY29-11
BLY28-L AN 4/0 3/8” 1.05 1.09 0.14 0.81 2.46
BLY28-L12 4/0 AWG 1/2” 1.05 1.09 0.14 0.81 2.63
BLY28-L13 5/8” 1.15 1.28 0.15 0.87 2.76
BLY28-L14 3/4” 1.15 1.28 0.15 0.87 2.76
BLY28-L1 + 1/4” 1.15 1.28 0.15 0.87 2.76
BLY28-L2 5/16” 1.27 1.44 0.15 0.87 2.96
BLY28-L6 7/16” 1.15 1.28 0.15 0.87 2.76
BLY28-L15 7/8” 1.15 1.28 0.15 0.87 2.76
1.15 1.28 0.15 0.87 2.76
1.27 1.44 0.15 0.87 2.96

• Not UL Listed + Not CSA Certified
