METALWORKING EQUIPMENT                                                                                                                                                                               METALWORKING EQUIPMENT
         AND TOOLS                                                                                                                                                                                            AND TOOLS
                                                PRECISION OF GEAR HOBBING                                                        form a kinematic connection between the tool and the work piece reaches 15 with the same

                                                                                                                                 number of kinematic chain shafts. The emergence of high-frequency components is caused by
                                    MACHINES WITH DIRECT ROTATION                                                                the superposition of errors in the intermediate gears of the kinematic chain of the machine and
                                                                                                                                 the frequency of their manifestation per revolution of the pitch wheel. Their value depends on

               This article discusses the main             OF TOOL AND WORKPIECE                                                 the gear ratio between the given gear and the final link.
        features  of  the  formation of  the
        kinematic  errors  of  new  generation
        gear  hobbing  machines  with  direct  drives  of  rotation  of  the  cutter  and  workpiece.  On  the
        experimental machine 5320F4 of class P accuracy, an accuracy was obtained that is five times
        higher than the accuracy according to GOST 659-89. The directions in the design and production
        of  these  machines  are  determined,  excluding  the  use  of  special  technologies  in  contrast  to
        traditional machines.
                                                                The peculiarity of the developments of modern
                                                        CNC machines is the modular design principle based on                                 Table rotation error (product
                                                        mechatronic modules. In this case, traditional kinematic
                                                        chains in machine  tools are  partially or completely
                                                        replaced by mechatronic devices, which, as a rule, are
                                                        functionally compatible with the executive bodies of the                                 spindle)      1 revolution of the table (product spindle)
                                                        machine. Gear hobbing machines are no exception [2].
                                                        When developing machine tools of a new generation,
                                                        most companies use direct drives to rotate the cutter                    Fig. 1. Graph of the kinematic error of the machine.
                                                        and the work piece, as a result of which the sources
                                                        of motion are located directly on the working body of
        the machine, while there are no intermediate gears between it and the final link. Consequently,                                 Thus, errors of the intermediate elements of the kinematic chain cause errors in it with
        clearances in gears are eliminated, high rigidity is provided when transferring rotation from the                        frequencies corresponding to the frequencies of errors of the constituent elements. Note that
        engine to the tool and work piece.                                                                                       the formation of the profile of the teeth of the wheels when working with a worm cutter occurs
               This solution makes it possible not to use precise gears, which have a decisive effect                            due to its bending around by the straight cutting edges of the cutter, therefore, in the end
        on the kinematic accuracy of the machine, which with direct drives is determined mainly by                               section of the tooth, the profile always has the curvature of the same sign, i.e. there can be
        feedback sensors and the dynamic characteristics of the drives and changes little (due to the                            no concave sections, regardless of the size and nature of the kinematic error of the machine.
        absence of wear) during operation. In addition, a number of advantages appear: simplification                            The tooth profile is created by a finite number of cutter teeth, therefore the cyclic error of the
        of the design of the machine as a result of a decrease in the number of original parts by about                          machine kinematic chain is reflected on the profile discretely - at the moment the table or cutter
        5 - 7 times; no restrictions on increasing the cutting speed, which provides the possibility of                          deviates from the ideal relative position when reproducing the profile point by the cutter tooth,
        using carbide tools and obtaining various modifications of the tooth in length, and also allows                          which affects the transfer of the machine kinematic chain error to the gear being processed [3].
        you to process gear wheels of high hardness.                                                                                    The maximum possible double amplitude of the sinusoidal error of the rolling chain is
               PRECISION OF GEAR WHEELS AND MACHINES                                                                             inversely proportional to the number Zд of the teeth of the pitch wheel in a square: δ = 2ν /
               For each degree of accuracy of gears according to GOST 1643-81, the following indicators                          Zд 2, where ν ≈ 21о is the angle of the involute. Therefore, to increase the accuracy of the
        are established: kinematic accuracy, smoothness of operation, tooth contact. Many performance                            machine, indexing wheels with a larger number of teeth are used.
        characteristics depend on the accuracy of the gears, including permissible peripheral speed and                                 KINEMATIC ERROR OF MACHINES WITH DIRECT DRIVES OF ROTATION OF THE
        durability. So, in turbine wheels, with a degree of accuracy of 4 - 3 - 4, a peripheral speed of                         WORKPIECE AND MILL
        130 m / s and more is achieved.                                                                                                 In MSTU  STANKIN,  the errors  were
               Kinematic  errors  of  hobbing  machines  equipped  with  hob  cutters  affect  the  first  two                   measured  on a  prototype  Ø200mm  machine
        indicators of the accuracy of gear wheels, in particular, the accumulated error of the circumferential                   5320F4  (accuracy  class  P),  designed  at  the
        pitch of the wheel is approximately 90 % dependent on the error of the machine, while the error                          State  Research  Center  MSTU  STANKIN  and
        in the direction of the tooth depends on the error of the machine by 50 %, and the error the                             manufactured at OJSC SASTA (Sasovo).
        profile of the teeth - by 25 % [3].                                                                                             Since  the  cyclic  errors  significantly
               The kinematic error of the machine is determined by the deviation from the theoretical                            depend  on the  tool and  the  cutting process,
        gear  ratio between  the  tool and  the  work piece at  each  point in time.  The accuracy of  the                       the  accuracy  of  the  machine  was  assessed
        kinematic chain of the interconnected position of the table (product spindle) relative to the                            by the kinematic  error  measured  at  idle by
        tool spindle is characterized by: the accumulated error φк.н. rotation and periodic (cyclic) error                       the  Diakin-3R  kinematometer,  with  errors  in
        φк.ц. (fig. 1). The reasons for the occurrence of kinematic error in machines with a mechanical                          measuring  the  accumulated  error  φк.н.  ≈  2"
        connection between the cutter and the work piece (traditional machines) and errors in machines                           and cyclic error φк.ц. ≈ 1". The measurements
        with direct drives of rotation of the cutter and table have fundamental differences.                                     were carried out under the following conditions:
               KINEMATIC ERROR IN TRADITIONAL MACHINES                                                                           the number of teeth when tuning for a single-
               Low-frequency  component  of  kinematic  error,  which  is  error  φк.н. due  primarily  to                       thread worm cutter Z = 6; 24 and 96; cutter
        manufacturing and installation errors dividing worm wheel of the table spindle, which are made                           rotation frequency n = 50 and 200 min-1; the
        up of the accumulated error of the circumferential step, radial and end beats [3, 4].                                    direction of  rotation  of  the  drives  is in both
               High-frequency component, error φк.ц. caused by the presence of errors in the intermediate                        directions.  The  rotation  control  of  the  cutter       Fig. 2. Vertical gear hobbing machine mod. 5320F4.
        gears of the kinematic chain. In medium-sized machines, the number of pairs of gears that                                and work piece drives was carried out by the
