METALWORKING EQUIPMENT                                                                                                                                                                               METALWORKING EQUIPMENT
         AND TOOLS                                                                                                                                                                                            AND TOOLS
                                                                                                                                 TESTS OF METAL CUTTING TOOLS COATINGS



                                                                           Thus,  when  increasing  the  dynamic                 FOR MICRO-ABRASIVE WEAR
                                                                   characteristics of the drives, special attention
                                                                   should be  paid to  the  table  rotation  drive,
                                                                   since in the used control system (Sinumerik
                                                                   840D, Siemens)  it is a  slave,  adjusting to                        Microabrasive  wear  is the  process
                                                                   the  master  drive  of  the  cutter,  while the               of  destruction  of  parts  operating  under
                                                                   connection between them is realized through                   sliding or rolling friction, in the presence of
                                                                   an electronic gearbox.                                        loose abrasive particles in contact  between
                                                                                                                                 rubbing surfaces with a size of less than 100
                                                                                                                                 microns  and a  hardness,  greater  hardness
                                                                                                                                 of materials of tribo-couplings. This type of
        Fig. 7. Graphs of the kinematic errors of the cutter drives (a, b)                                                       wear is experienced, for example, by open plain bearings, machine tool guides, gears of open
        and the table (c) with various settings                                                                                  gears and gearboxes, hinged joints of chains of various machines, etc. In addition, due to the

        Findings                                                                                                                 formation of wear products involved in friction processes, the possibility of oil coking, ingress
        ● Experimental studies of the kinematic error of the 5320F4 machine tool with a new generation                           abrasive particles into the lubricant when the tightness of the lubricating system is broken,
        of accuracy class P with direct drives of rotation of the cutter and work piece showed a significant                     almost all surface layers of tribo-couplings are also under the influence of microabrasive wear.
        increase (more than 5 times) in the kinematic accuracy, which is higher than the accuracy of the                                The study of this type of wear is relevant for parts and tools with wear-resistant thin-film
        class A machine. It was found that the greatest influence on the accuracy of the machine has                             coatings  deposited  using  PVD  and  CVD  processes,  when  choosing  the  optimal  technological
        dynamic characteristics of the table drive.                                                                                                                                                 mode  for  applying  the  same  coating
        ●  New  generation  machines  for  accuracy  classes  from  H  to  A  should  be  based  on  a  single                                                                                      material and when studying the effect
        machine model of the same size with 90 - 95 % standardization of parts.                                                                                                                     of the chemical composition, type and
        ● Due to a significant increase in the manufacturability of units that provide shaping, the production                                                                                      physical  and  mechanical  properties
        of new generation machine tools does not require special equipment and technologies (master                                                                                                 of  various coatings.  The  international
        machines for processing worm wheels and worms, etc.). This production can be realized not                                                                                                   standard  EN  1071-6:  2007  has  been
        only at specialized enterprises, as in the manufacture of traditional gear hobbing machines, but                                                                                            developed  for  testing  microabrasive
        also at any machine-tool plant, which was shown by the practice of manufacturing horizontal                                                                                                 wear of such coatings. Abroad, this type
        machines at LLC Morena (Kolomna) and vertical machines at JSC SASTA (Sasovo).                                                                                                               of testing is most often used to assess
                                                                                                                                                                                                    the  tribological properties  of  coatings,
                                                                                                                                                                                                    along  with indentation  processes  and
                                                                                                                                                                                                    friction tests [1].
                                                                                                                                                                                                           Determination of wear parameters
                                                                                                                                                                                                    under conditions of microabrasive wear
                                                                                                              A.V. Novikov,                                                                         is based  on  microscopic measurement
                                                                                   post-graduate student of the Machine tools    Fig. 1. General view of the equipment for testing of microabrasive
                                                                                               department of MSTU STANKIN        wear.                                                              of  an  indentation  obtained  at  point
                                                              .                                                                                                                                     contact of two mating bodies - a freely
        References:                                                                                                                                                                                 rotating steel ball and a stationary flat
        1. Bushuev V.V., Kuznetsov A.P., Sabirov F.S., Khomyakov V.S., Molodtsov V.V. State and directions of development of scientific
        research in machine tool industry // STIN. 2015. No. 11. pp. 12 - 20.                                                    sample with a coating (or without a coating) in the presence of an abrasive suspension in the
        2. Bushuev V.V., Novikov V.A. Directions of development of gear-processing equipment // Bulletin of MSTU STANKIN. 2015. No.   friction zone. A prerequisite for measurements is a clear image of the wear print and contrast
        2 (33).                                                                                                                  of the coating and substrate, determined by the roughness of the coated sample. Tests are
        3. Bushuev V.V., Naletov S.P. Heavy gear cutting machines. Moscow. Mashinostroenie, 1986. 280 p.
        4. Levashov A.V. Basics of calculating the accuracy of kinematic chains of metal-cutting machines. Moscow. Mashinostroenie,   carried out in the conditions of an inclined position of the sample and pressing the ball against
        1966. 211 p.                                                                                                             it due to its own mass. The presence of a certain amount of abrasive suspension in the area of
        5. Molodtsov V.V., Bushuev V. V. Methodology for modeling feed drive mechanisms for CNC machine tools // Bulletin of mechanical   friction between the ball and the sample provides a quick impression with wear of the coating
        engineering. 2015. No. 8.
        6. Molodtsov V.V., Bushuev V. V., Evstafieva S.V. Simulation of control loops of the servo feed drive // STIN. 2016. No. 3. pp.   and substrate.
        7 - 14.                                                                                                                         The load in the contact friction zone is constant when using the same balls (dimensions,
        7. Gilovoy L.Ya., Molodtsov V.V. Designing gear hobbing machines with hightened rigidity // Handbook. Engineering journal with   roughness parameters and material) and their positioning relative to the test specimen. The
        annex. 2013. No. 2 (191). pp. 40 - 45.
        8. Makarov V.M., Churilin A.V., Korendyasev G.K. Technological support for the accuracy of gear parts based on new technologies   wear conditions of the samples are the same at the constancy of the balls, the rotation speed of
        and modeling // Machine building technology. 2010. No. 7. 27 p.                                                          the drive shaft, the test time, the use of the same abrasive suspension and a constant amount
                                                                                                                                 or rate of its introduction.
                                                                                                                                        The principle of microabrasive wear is the action of cohesively strong micron-sized abrasive
                                                                                                                                 particles contained in an abrasive suspension, which are located in the gap between two surfaces
                                                                                                                                 during friction. At the same time, they cut the contacting surfaces, acting as an abrasive tool.
                                                                                   CREATE A BETTER FUTURE                        Under  conditions of  rotation  of  a  ball with a  large  diameter  relative  to  a  stationary  coated

                                                                        TOGETHER WITH OUR CUSTOMERS                              specimen, abrasive particles are removed from the test specimen the roughness protrusions
                                                                                                                                 and the coating itself on the dotted surface, polishing and smoothing it, with the formation of a
                                                                                                                                 spherical wear segment.
                                                                                                                                        Equipment  for  determining  wear  parameters  using microabrasive  wear  tests consists
                                                                                                                                 of  a  Tribotester  PC102  tribotester  (manufactured  by  Plasmacenter  LLC)  with a  set  of  balls,
