P. 98
Integrated Coil Brackets
What to do with those pesky coils in such
LS Slant Edge Covers a confined space. A unique rail mounting
These new valve covers are taller system attaches to the threaded holes on
than stock valve covers and can the valve cover, and the individual coils
attach to the rail so they can be mounted in
accommodate a wide variety of large multiple positions. All necessary hardware
valve train applications. Fits GM LS included.
engines only. PFM141-257 Part No. Description
Part No. Description PFM69520* .....Coil Bracket For LS 1 Style Coils
PFM141-261 ....Chevy Orange, Raised Emblem
PFM141-262 ....Black Crinkle, Raised Emblem PFM69521* .....Coil Bracket For LS 3 And 7 Style Coils
PFM141-263 ....Cast Gray, Raised Emblem * MSD 39849 13"-15" longer sparkplug wires are needed
PFM141-264 ....Polished, Recessed Red/Black Emblem
PFM141-265 ....Chromed, Recessed Red/Black Emblem Coil Relocation Extension Cords
PFM141-266 ....Polished, No Emblem If you're thinking of relocating your LS igni-
PFM141-257 ....Chevy Orange, Raised LSX Emblem NEW tion coils somewhere out of sight, then you'll
need at least one of these extension cords
Cylinder Head Valve Cover because you'll have to relocate the wiring har-
Mounting Bolts PFM66330 ness also. Includes authentic Delphi connec-
tors and is built and tested to withstand life in
These 8 mounting bolts are necessary to mount the engine compartment. Sold as individual cords.
Chevrolet and Bowtie LS valve covers part numbers Part No. Description
141-257, and 141-261 thru 141-266 to LSX-DR PFM69525.......18" Extension Cord
cylinder Heads. PFM69526.......46" Extension Cord
Exhaust Systems
Exhaust Systems deliver enhanced perfor-
mance, provide extra punch in the passing lane
and improve gas mileage. Systems feature all 16-gauge,
2010-13 Camaro Headers mandrel-bent pipe for maximum exhaust gas flow and
significant horsepower gains.
PYPHDR150S Part No. Description
Formed from 304 polished stainless steel and have a tube diameter of PYPSGF52K ...... 2010-13 Camaro 3.6L, Cat Back, M80 Mufflers 4" Tips
1-3/4". High quality gaskets and hardware included. Collector diameters PYPSGF53........ 2010-14 Camaro 6.2L, Axle Back Pype Bomb, Muffler Delete
are 2.5". 24" 02 sensor extensions required. Tailpipes 4" Tips
PYPSGF50K ...... 2010-13 Camaro 6.2L, 2.5" w/X-Pipe Cat Back M-80 Muffler
4" Tips
Polyurethane Bushings Heavy Duty Engine Mounts
PTN7-512BL
PTN7-2044BL
1998-02 LS1 Heavy duty engine mounts are
durable, black urethane that limit movement and
control torque for improved handling. Mounts
perform like steel, but without the vibration. Sold
in pairs.
PTN7-518BL
Prothane offers a wide variety of polyurethane bushings that will im-
prove handling quality of the 2010-14 Camaro. Pro-Motion bushings will
last much longer and will not deteriorate like rubber bushings. Bushings
improve handling, ride quality, and engine stability.
Part No. Description
PTN7-142BL .... Rear Subframe Bushings, Black
PTN7-318BL .... Rear Control Bushings, Black
PTN7-518BL .... V8 Motor Mounts, Black
PTN7-703BL .... Rack and Pinion Bushings Set, Black
PTN7-2044BL ... Total Kit with Full Replacement Sub-Frame Bushings
PTN7-1613BL ... Differential Mount Kit
PTN7-1214BL ... Rear Link Kit (Toe And Trailing Arm)
PTN7-239BL .... Front Forward C-Arm Insert Kit
PTN7-319BL .... Rear Control Arm (Upper & Lower)
2016-17 CAMARO PRODUCTS 97
