Circuit-System circuit diagram

: Part position

Reference wire
S/N S/N Reference wire harness S/N Reference wire harness
harness
B050 Body wire C017 Chassis wire C049 Chassis wire

C013 Body wire C018 Chassis wire C051 Chassis wire
C014 Chassis wire C019 Chassis wire C052 Chassis wire
C015 Chassis wire C020 Chassis wire
C016 Chassis wire C033 Chassis wire

: Insert parts between wire harnesses

S/N S/N Reference wire harness (position of the insert parts)
B103 C101 Body wire and chassis wire (middle of the first cross member of frame)
C104 B106 Body wire and chassis wire (middle of the first cross member of frame)

: Grounding
S/N Grounding position
C216 Chassis wire is grounded

C237 Chassis wire is grounded
C238 Chassis wire is grounded
