Circuit-Information of wire insert parts
D006 turn lamp on the side of right door D101 connect to body wire
Terminal Terminal
Color Function Remarks Color Function Remarks
No. No.
Right side Rise, left front
1 W-B turn lamp 1 G-B power window
(-) switch
Right side Lock controller
2 B-B
2 G-Y turn lamp is started
(+) Fuse, power
3 B-R
window
Radio and
4 B-B cassette player
(FR+)
Descend, right
5 G-Y front power
window switch
Lock controller
6 B-Y
is locked
Grounding, body
7 W-B
wire
8 G-Y Right turn lamp Null
9
61 Radio and
10 Blue cassette player
(FR-)
