Page 56 - Vessel Sanitation Program 2018 Construction Guidelines

VSP 2018 Construction Guidelines

14.1.3 Cleanout Ports
Install cleanout ports in the direct exhaust ducts of the ventilation systems
between the top of the warewashing machine and the hood system or
DECKHEAD.

14.1.4 Drip Trays
Provide ACCESSIBLE and REMOVABLE condensate DRIP TRAYS in
warewashing machine ventilation ducts. A dedicated drainage pipe from the
DRIP TRAYS to a GUTTERWAY or a DECK DRAIN is also acceptable.

14.2 Cooking and Hot-Holding Equipment

14.2.1 Cooking Equipment
Install hood or canopy systems above cooking equipment in accordance with
safety of life-at-sea (SOLAS) requirements to ensure they remove excess steam
and grease-laden vapors and prevent condensate from collecting on surfaces.

40
