P. 28
1300 527 668 KARMOT PTY LTD
MINI BOTTLE JACKS
Super low profile small jack. Convenient for delicate work such as fine adjusting or centring
of heavy machinery.
Made in Japan
MMJ-5C
MMJ-10C
INDUSTRIAL BOTTLE JACKS
MMJ-20C
Part Number Working Load Limit Closed Height Lift Maximum Height Base Area Weight
MMJ5C 5,000kg 65mm 20mm 85mm 74mm Dia. 1.9kg
MMJ10C 10,000kg 120mm 30mm 150mm 108mm Dia. 5.5kg
MMJ20 20,000kg 130mm 30mm 160mm 120mm Dia. 8kg
INVERTED PRESS JACK
Handle socket modified for use when inverted. (Return springs not
supplied) Made in Japan. High quality for long service life, used in
Australian presses for over 35 years!
Part Number Working Load Limit Stroke Extension Screw Base Area
MH-10PJ 10,000kg 150mm 80mm 166mm x 106mm
MH-15PJ 15,000kg 165mm 80mm 180mm x 118mm
MH-20PJ 20,000kg 160mm N/A 182mm x 128mm
Page 22 www.karmot.com sales@karmot.com
