TOE JACKS

Masada Toe Jacks are Ideal jack for lifting loads with a low minimum jacking clearance.

Uses an internal slide rail system for long life, self retracting eliminating manual lowering,

also the Handle swivels 180° for operating in any direction. Some applications could be,

house moving, machinery installation, applications at shipyards, bridge building, plant

construction sites, and forklift service.

Made in Japan

MHC-10RS
MHC-5RS MHC-2RS

Part Working Load Limit Closed Height Lift Toe Maximum Height Base Area Weight
Number Head / Toe Head / Toe Head / Toe

MHC-2RS 5,000 / 2,000kg 243 / 19mm 113mm 350 / 132mm 227mm x 160mm 12.5kg INDUSTRIAL BOTTLE JACKS
MHC-5RS 10,000 / 5,000kg 290 / 22mm 120mm 410 / 142mm 262mm x 182mm 18.5kg

MHC-10RS 20,000 / 10,000kg 325 / 28mm 145mm 470 / 173mm 280mm x 225mm 35kg

LOCK RING JACKS

These high quality bottle jacks use a lock ring located on the

threaded ram of the jack to hold the job in a specified position.
This type of jack is commonly used for fine adjustment of heavy

machinery and heavy constructions, such as bridge building.

Made in Japan

Part Working Load Closed Lift Extension Screw Maximum Weight
Number Limit Height Height Height

MH-10LS 10,000kg 300mm 165mm 80mm 545mm 13kg
MH-20L 20,000kg 310mm 160mm N/A 470mm 15.3kg
